Lynx OET-1510-MM - 1GbE to Fiber Transceiver (Multi-mode, 850nm, LC connectors)

1085671
Lynx OET-1510-MM - 1GbE to Fiber Transceiver (Multi-mode, 850nm, LC connectors)
Lynx OET-1510-MM - 1GbE to Fiber Transceiver (Multi-mode, 850nm, LC connectors)
The yellobrik O DT 1510 Singlemode Serial & GPI Fiber Transceiver from Lynx Technic AG is a multi-function module which when used with another ODT 1510 (sold separately) in a remote location can extend the reach of serial RS-232, RS-422, or RS-485 as well as 2 GPI (general purpose I/O) up to 6.2 mi over fiber.
... mehr erfahren
Visuals Preis
599,00 CHF o. MwSt.

647,52 CHF Inkl. MwSt

Auf Bestellung
  • Lieferung
    • Versand in 1 bis 2 Wochen
  • Abholung im Geschäft
    • Verfügbar in 1 bis 2 Wochen

Lynx OET-1510-MM Specs

Ethernet 2 x Ethernet ports, RJ 45 Connectors.
10 BaseTUTP category 3,4 or 5 cable up to 328ft/100m (2 pairs)
100 BaseTXUTP category 5 cable up to 328ft/100m (2 pairs)
1000 BaseTXUTP category 5 cable up to 328ft/100m (4 pairs)
Auto detect bit rate (10/100/1000), or force to 10Mbit for each port (selectable)
Automatic crossover detection or force manually for each port (selectable)
Port speed / activity LED indication (next to Ethernet port)
Fiber Optic 1 x fiber optic input (TX)
1 x fiber optic output (RX)
Duplex using LC/PC Connections
IEEE 802.3z (1000BASE-X Gbit/s Ethernet over Fiber at 1 Gbit/s (125 MB/s))
Singlemode Version: TX wavelength 1310nm, power -3dBm; RX input range 1260nm to 1620nm, sensitivity -3dBm to -21dBm; Max distance 10km (6.2 miles)
Multimode Version: TX wavelength 850nm, power -2dBm to -7dBm; RX input 850nm, sensitivity 0dBm to -15dBm; Max distance approx 550m (1804 feet)
Fiber TX active and RX active LEDs on side of module
Physical Power: +12VDC @ 2.2W nominal - (supports 7 - 15VDC input range)
Size: 120 x 42 x 22mm (4.73 x 1.65 x 0.86") including connectors
Weight: 125g (4.4oz)
Ambient: 41 - 104°F, 90% Humidity (non condensing)
The yellobrik O DT 1510 Singlemode Serial & GPI Fiber Transceiver from Lynx Technic AG is a multi-function module which when used with another ODT 1510 (sold separately) in a remote location can extend the reach of serial RS-232, RS-422, or RS-485 as well as 2 GPI (general purpose I/O) up to 6.2 mi over fiber.
