Atomos - A-Eye 4K-12X - PTZ Camera
Atomos ATOMAE4K12 - A-Eye 4K-12X - PTZ Camera
1083944
Add a high-resolution streaming and tracking camera to your classroom, house of worship, or conference room for remote meetings with software such as Skype, Microsoft Teams, or Zoom with the A-Eye 4K-12X PTZ Camera with 12x Optical Zoom from Atomos ATOMos.
Visuals Preis
1.388,45 CHF
o. MwSt.
1.500,91 CHF Inkl. MwSt
Herstellerpreis 1 461,53 CHF zzgl. MwSt.
Auf Bestellung
-
Lieferung
- Versand in 2 bis 3 Wochen
-
Abholung im Geschäft
- Verfügbar in 2 bis 3 Wochen
Atomos ATOMAE4K12 Specs
| Dimensions (W x H x D mm) | 146mm x 169mm x 168mm |
| Weight | About 1.6Kg |
| Ambient operating temperature | Up to 40 degrees Celsius |
| Body | ABS |
| Input voltage | DC 12V/PoE+ (802.3at) |
| Operating power | Max 18W |
| Power on indicator | Yes |
| Sensor | 1/2.5 inch, CMOS |
| Effective pixels | 8.51M |
| Lens | 12x, f = 4.4mm ~ 52.8mm, F1.8 ~ F2.6 |
| Scanning mode | Progressive |
| Resolutions supported | HDMI: 4KP60, 4KP50, 4KP30, 4KP25, 4KP59.94, 4KP29.97, 1080P60, 1080P50, 1080P59.94, 1080P30, 1080P29.97, 1080I60, 1080I50, 1080I59.94, 720P60, 720P59.94 3G-SDI: 1080P60, 1080P50, 1080P30, 1080P29.97, 1080P59.94, 1080P25, 1080I60, 1080I50, 1080I59.94, 720P60, 720P59.94 |
| Color system / compression | YUY2/H.264/MJPEG/H.265 |
| Video format | YUY2: max to 1080P@5fps; H.264/AVC: max to 2160P@30fps; H.265 HEVC: max to 2160P@30fps; MJPEG: max to 2160P@30fps |
| Digital zoom | 16x |
| Minimum Illumination | 0.5 Lux @ (F1.8, AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| Image flip | Supported |
| Image freeze | Supported |
| White balance | Auto, VAR, Manual, One Push, Indoor, Outdoor |
| Backlight compensation | Support |
| Digital noise reduction | 2D & 3D Digital Noise Reduction |
| SNR | ≥55dB |
| Horizontal FOV | 71° ~ 8.2° |
| Vertical FOV | 42.7° ~ 4.5° |
| Pan angle | ±170° |
| Tilt angle | -30° ~ +90° |
| Pan speed | 1.7° ~ 100°/s |
| Tilt speed | 1.7° ~ 69.9°/s |
| Preset position | 255 |
| Preset accuracy | 0.1° |
| Operating system (USB) | Windows 7/8/10, Mac OS X, Linux, Android, iOS, iPadOS |
| USB audio | Supported |
| USB video protocol | UVC 1.1/UVC 1.5 |
| USB PTZ control | Supported |
| Video compression | H.264/H.265/MJPEG |
| Video stream | First Stream, Second Stream |
| First stream resolution | 3840x2160, 1920x1080, 1280x720, 1024x576, 720x480, 720x408, 640x480, 640x360 |
| Second stream resolution | 720x480, 720x408, 640x480, 640x360, 480x320, 320x240 |
| Video bit rate | First Stream: 32kbps~51200kbps; Second Stream: 32kbps~20480kbps |
| Bit rate control | CBR, VBR |
| Frame rate | 50Hz: 1fps ~ 50fps; 60Hz: 1fps ~ 60fps |
| Audio compression | AAC |
| Audio bit rate | 96Kbps, 128Kbps, 256Kbps |
| Protocols | NDI HX3, TCP/IP, HTTP, RTSP, RTMP/RTMPS, ONVIF, DHCP, SRT, Multicast |
| Microphone | No built-in mic |
| Audio input | Line In |
| Audio output | Line Out, HDMI, USB |
| Line In | 3.5mm audio interface |
| Line Out | 3.5mm audio interface |
| RS-485 | 2-pin phoenix port; max distance: 1200m; protocol: VISCA/Pelco-D/Pelco-P |
| RS-232 IN | 8-pin Mini DIN; max distance: 30m; protocol: VISCA/Pelco-D/Pelco-P |
| RS-232 OUT | 8-pin Mini DIN; max distance: 30m; protocol: VISCA network use only |
| Network | 10M/100M Adaptive Ethernet Port |
| USB | USB 2.0: Type A |
| 3G-SDI | BNC type, 800mVp-p, 75Ω. To SMPTE 424M standard |
| HDMI | HDMI version 1.3 |
| Power jack | JEITA type (DC IN 12V) |
| Tally indicator | Yes |
| Box Contents | A-Eye 4K-12X PTZ camera, RS-232 serial cable (2m), USB 3.0 A-A cable (1.5m), lens cover, remote controller, accessory tray, wall mount rack, screw pack, power adaptor with 4 plugs, Quick Start Guide |
| Warranty | Standard 1 year. Extended to 2 years on product registration. |
Add a high-resolution streaming and tracking camera to your classroom, house of worship, or conference room for remote meetings with software such as Skype, Microsoft Teams, or Zoom with the A-Eye 4K-12X PTZ Camera with 12x Optical Zoom from Atomos ATOMos.
