AJA - KUMO 64x64 Compact 12G-SDI Router

AJA KUMO-6464-12G-1 - KUMO 64x64 Compact 12G-SDI Router

1084073
AJA KUMO-6464-12G-1 - KUMO 64x64 Compact 12G-SDI Router
AJA KUMO-6464-12G-1 - KUMO 64x64 Compact 12G-SDI Router
AJA KUMO-6464-12G-1 - KUMO 64x64 Compact 12G-SDI Router
AJA KUMO-6464-12G-1 - KUMO 64x64 Compact 12G-SDI Router
KUMO 64x64 Compact 12G-SDI Router, with 1 Power Supply
... en savoir plus
Prix Visuals
13 536,60 CHF HT

14 633,06 CHF TTC

Prix constructeur 14 249,05 CHF HT
Sur commande
  • Livraison
    • Expédié dans 2 à 3 semaines
  • Retrait en boutiques
    • Disponible dans 2 à 3 semaines

AJA KUMO Specs

Processing
Switching Type Software
Input
Video Inputs 64x BNC (12G-SDI) Female
Input Video Format BNC
8K
UHD 4K
Output
Video Outputs 64x BNC (12G-SDI) Female
Output Video Format SDI
8K
UHD 4K
Connectivity
Other I/O 2x BNC Reference Input
1x RJ45 Control, LAN Input/Output
1x Mini-USB Firmware, Service Input
1x DE-9/DB-9 Control, RS-422 Input/Output
Video Standard Compliance SMPTE 259M/292M/424M/ST 2081-10/ST 2082-11
Hardware
Wireless No
Power
Power I/O 2x Block 4-Pin (100 to 240 VAC) Input
Power Consumption Power Supply: 100 to 240 VAC (84 W)
Device: 10 to 14 VDC (50 W)
General
Operating Conditions 32 to 104°F / 0 to 40°C at 10 to 90% Humidity
Storage Conditions -40 to 140°F / -40 to 60°C
Rack Form Factor 4 U
Dimensions 17.4 x 7 x 1.5" / 44.1 x 17.7 x 3.9 cm
Weight 9.3 lb / 4.2 kg
Packaging Info
Package Weight 9.215 lb
Box Dimensions (LxWxH) 24.5 x 12.9 x 5.2"
KUMO 64x64 Compact 12G-SDI Router, with 1 Power Supply
