A new benchmark in creative flexibility
The HDC-3500 system camera brings new levels of image quality, portability and creative flexibility to live production environments. Enjoy premium 4K/HD/HDR image quality – and anticipate tomorrow's production needs whilst maintaining full compatibility with today's workflows and system hardware.
Unleashed imaging power
Capture premium images with the world's first 2/3-inch 4K CMOS sensor featuring global shutter technology that eliminates "jelly" effect and banding noise. This allows the HDC-3500 to capture flawless 4K images with exceptionally low noise (-62 dB), impressive sensitivity (F10 at 1080/59.94p or F11 at 1080/50p) and high dynamic range, whilst achieving the ITU-R BT.2020 broadcast standard wide colour gamut. It is paired with a specially developed digital signal processing LSI that fully exploits the extraordinary imaging power of this new sensor.
More format flexibility
The HDC-3500 can deliver 3G-SDI signals in a range of formats up to 1080/50p, with 4K available via the CCU's 12G-SDI and Quad 3G-SDI interfaces. This gives you maximum production convenience – and your viewers can enjoy premium image quality.
Get the look
Expand your creative possibilities and achieve exactly the look you want in any shooting situation. Low-light saturation ensures rich, vibrant colours in dark areas. Powerful gamma functions offer absolute control over fine-tuning of tonal values, contrast and detail.
Features
Easy transmission changeover
The HDC-3500 supports optical fibre transmission as standard, with a SMPTE standard interface for connection with the associated HDCU-3100/HDCU-2000 camera control units. It's quick and easy to reconfigure the camera at any time for fibre, third-generation digital triax or wireless operation with a choice of optional outer panels.
Broader workflow options
Support for Sony's SR Live for HDR workflow enables simultaneous 4K HDR and HD SDR production by a single crew – reducing hardware and personnel costs for multi-format productions. Additionally, the HDC-3500 can be upgraded via optional software licences to add progressive signal capture, progressive segmented frame (PsF) signal or double-speed acquisition functions for exquisite slow motion.
The camera that goes anywhere
Combining exceptional lightness and strength, the magnesium alloy housing is complemented by carbon fibre-reinforced plastic (CFRP) outer panels. Safe, stable handling is enhanced by the camera's low centre of gravity, its easily adjustable shoulder pad and expanded grip area. Also ideal for shoulder-mounted use, HDC series studio cameras offer exceptional user ergonomics in a wide range of studio and field production environments.
Seamless integration
Backward compatibility with Sony's industry-recognised HDC-2000 series system cameras simplifies smooth integration with your current live production infrastructures, including cameras and CCUs.
Smooth slow motion
The HDC-3500 offers a double-speed acquisition function, transmitting high-quality Full HD images to the HDCU-3100 or HDCU-2500 camera control unit (CCU).
Camera number and tally display
The assigned camera number is indicated on the camera body by an electronic paper graphic display. The displayed information is updated automatically to reflect system changes. There is also an LED tally lamp next to the camera number display.
Rich focus assist functions
The Viewfinder Detail function adds dedicated image enhancement outline signals directly to the viewfinder, helping the operator to focus quickly and accurately in any shooting situation. It is complemented by a focus assist indicator and an advanced focus position measurement function.
Servo-controlled ND and CC filters
Two optical filter wheels for neutral density (ND) and colour correction (CC)* open up wider creative possibilities. Both filters can be controlled from a remote control panel, a master setup unit or directly from the camera head.
Network TRUNK
Network TRUNK (via LAN port) enables high-speed data transmission between camera and CCU up to 1 Gbps to support configurability with IP-based products and systems. Camera operating in fibre configuration.
|
|
Specifications |
|
|
General |
|
|
|
Power requirements |
AC 240 V, 1.4 A (max.), DC 240 V, 1.05 A (max.) |
|
|
Operating temperature |
−20 °C to +45 °C (−4 °F to 113 °F) |
|
|
Storage temperature |
−20 °C to +60 °C (−4 °F to 140 °F) |
|
|
Mass |
Approx. 4.9 kg (10 lb 13 oz) (Unit only) Approx. 5.1 kg (11 lb 4 oz) (when HKC-TR37 is attached) Approx. 4.9 kg (10 lb 13 oz) (when HKC-FB30 is attached) |
|
|
Image sensor |
|
|
|
Image sensor |
2/3-inch type 4K CMOS sensor with global shutter |
|
|
Method |
3-CMOS, RGB |
|
|
Electrical |
|
|
|
Sensitivity |
F10 with 1080/59.94p F11 with 1080/50p (at 2,000 lx with 89.9% reflectance) |
|
|
Signal-to-noise ratio |
−62 dB or more |
|
|
Horizontal resolution |
1,000 TV lines (centre of screen), 5% or more modulation |
|
|
Geometric distortion |
Negligible (excluding lens distortion) |
|
|
Optical system |
|
|
|
Spectrum System |
F1.4 prism |
|
|
Built-in filters |
ND filters 1: CLEAR, 2: 1/4ND, 3: 1/8ND, 4: 1/16ND, 5: 1/64ND CC filters A: cross filter, B: 3200K (clear), C: 4300K, D: 6300K |
|
|
Input/output connectors |
|
|
|
CCU |
Electro-optical connector (LEMO 3K.93C connector) (x1) |
|
|
Lens |
12-pin (x1) |
|
|
VF |
20-pin (x1) |
|
|
MIC 1 IN |
3-pin XLR, female (x1) |
|
|
AUDIO IN CH1, CH2 |
3-pin XLR, female (x1 each) MIC AUDIO switch: −60 dBu (can be selected up to −20 dBu in menu), balanced LINE AUDIO switch: 0 dBu, balanced |
|
|
Intercom 1, Intercom 2 |
5-pin XLR, female (x1 each) |
|
|
Headphone |
4-pole mini-jack (x1), (2-pole mono, 3-pole stereo, 4-pole CTIA standard, 4-pole OMTP standard) |
|
|
DC IN |
4-pin XLR (x1), DC 10.5 to 17 V |
|
|
DC OUT |
4-pin (x1), DC 10.5 to 17 V, max. 0.5 A, 2-pin (x1), DC 10.5 to 17 V, max. 2.5 A BNC (x1) BNC (x1) |
|
|
SDI MONI |
BNC (x1) |
|
|
Test Out |
BNC (x1) |
|
|
Prompter/GENLOCK |
BNC (x1) Prompter 1 Vp-p, 75 Ω GENLOCK HD: SMPTE ST274, tri-level sync, 0.6 Vp-p, 75 Ω, SD: Black burst (NTSC: 0.286 Vp-p, 75 Ω/PAL: 0.3 Vp-p, 75 Ω) |
|
|
Prompter 2 |
BNC (x1), 1 Vp-p, 75 Ω |
|
|
RET CTRL |
6-pin (x1) |
|
|
Remote control |
8-pin (x1) |
|
|
Tracer |
12-pin (x1) |
|
|
Crane |
12-pin (x1) |
|
|
USB |
USB 2.0 Type A 4-pin (x1) (for connecting USB memory stick) |
|
|
Network Trunk |
RJ-45 type 8-pin (x1) |
