Blueshape - 3STUDS Li-Ion Battery, WIFI SYSTEM

Blueshape BG150 TWO - 3STUDS Li-Ion Battery, WIFI SYSTEM

190890
No image available
3STUDS Li-Ion Battery 150 Wh 10 Ah (4,5 mm tick), WIFI SYSTEM
... learn more
Visuals Price
469.06 CHF VAT excl.

507.05 CHF Inc. VAT

Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

BLUESHAPE GRANITE TWO 150Wh high-capacity Gold Mount battery

Designed for use in professional video applications, the BLUESHAPE GRANITE TWO batteries add new Wi-Fi connectivity to the feature list of the original GRANITE battery series. They are also available in Gold mount in addition to V-mount options. Externally, these batteries are designed to withstand the rigours of a film set. The textured finish is easy to grip and resists marks caused by drops and impacts. The interior and exterior have been tested to survive multiple vertical drops from up to 1.8 metres onto hard surfaces. The reinforced Gold mount is compatible with most Gold mount chargers.
In addition to being robust, GRANITE batteries are also powerful. Cameras and lights can draw up to 9 amps, between the main battery output and the two D-taps on the sides. As well as providing 14.8 volts of power, each D-tap can be used to charge the battery with a separately sold D-tap charger. As an additional protective measure, the D-taps are fitted with rubber caps which help maintain the IP54 rating against moisture and dust ingress.
Whilst the 5-LED battery indicator is useful and practical, BLUESHAPE offers a free iOS/Android app that can monitor and control various aspects of the battery, entirely wirelessly, via Wi-Fi. The app updates in real time based on current capacity, charge rate and power consumption. On set, all batteries can be monitored on the same network, so not only can you know in advance when to get a fresh battery, but also which battery is ready to use without having to guess.
GRANITE Link
Features
The GRANITE TWO batteries are the first generation to introduce BLUESHAPE's GRANITE LINK, a Wi-Fi communication feature enabling real-time remote monitoring via a free iOS/Android mobile app. Using GRANITE LINK, you can check data such as state of charge, estimated time until full discharge, cell temperature, remaining capacity, full charge capacity and cycle count. The state of charge and remaining runtime are updated in real time based on actual charging conditions.
Practical use cases
An operator, camera assistant or technical director can easily monitor the status of nearby batteries without having to physically press the button to check the battery itself. Multiple batteries can be monitored simultaneously from a single device. Additional features via the app allow identification, locking, unlocking and connection to a different network. A rental mode is available to limit the usage period when the battery is hired.
Network
The batteries can create their own Wi-Fi network to monitor a single battery, or can be connected to a main Wi-Fi network. A fleet of batteries can be easily monitored by multiple devices without complicated pairing procedures. The batteries can be given custom names for easy identification.
Construction
Internal modular design
The lithium-ion cells are secured inside the pack in a carefully designed and reinforced modular cage. All metal interconnections and the electronic monitoring board are integrated with the cells, forming a single core. No vulnerable wiring is used. The metal tabs between the cells have been thickened with a low-resistance alloy.
Solid external construction
The external mount is screwed to the internal core by means of a reinforced metal plate at the base of the battery housing. The external battery pack shells wrap around the internal core and secure it with 8 perimeter screws. A coloured rubber seal is sandwiched in the middle of the external shells to improve weather resistance and battery aesthetics.



Specifications





Mount type / Series

Gold Mount



Chemistry

Lithium-ion



Capacity (Wh)

150 Wh



Ampere-hours

10 Ah



Output voltage

14.8 V DC



Maximum load

9 A



Accessory port

2 x D-Tap



Maximum load (Accessory port)

5 A (D-Tap)



IP rating

IP54



Dimensions (L x H x D)

3.7 x 6.7 x 2.1" / 9.5 x 17.1 x 5.3 cm



Weight

2.62 lb / 1.19 kg
