Variosystems VS-OS-95-00515 - Capture Card

1012187
0850189006818
Variosystems VS-OS-95-00515 - Capture Card
Variosystems VS-OS-95-00515 - Capture Card
4x 12G SDI, Embedded 8 Stereo Audio Pairs per Channel
... learn more
Visuals Price
1,807.43 CHF VAT excl.

1,953.83 CHF Inc. VAT

Manufacturer price 1 902,56 CHF VAT excluded
Made to order
  • Delivery
  • In-store pickup

Variosystems capture card
The Osprey Raptor 1245 offers four 12G-Gb/s ports. The ports support SD, HD, Ultra HD and 4K DCI.
All Raptor 12xx cards can record at 60 fps.
Each individual SDI input supports 16 audio channels (8 stereo channels).
Features
- PCIe capture card
- 60 fps recording
- Four 12G-Gb/s ports - SD, HD, Ultra HD, 4K DCI
- SDI audio input supports 16 channels (8 stereo) per port
- Closed caption support
- Watermark overlay
- scaling
- Frame rate conversion
- SimulStream



Specifications



PCI format

PCI Express Gen2 (8x)

Slots: 8x or 16x

Video connections

4x 12Gb/s SD/HD/3G-A/2K/4K (Micro HD BNC)

Video standards

525i 59.94 NTSC, 625i 50 PAL

720p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

1080psf 23.98, 24, 25, 29.97, 30

1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

1080i 50, 59.94, 60

2K DCI 23.98p, 24, 25, 29.97, 30, 50, 59.94, 60

2160p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

4K DCI 23.98, 24, 25, 29.97, 30, 50, 59.94, 60

Audio input

Embedded SDI - 8 stereo pairs per SDI input

SDI compliance

SMPTE 259/292/296/424/425/2081/2082, ITU-R BT.656 and ITU-R BT.601

3G-SDI Level A only

Supported SDI metadata

CEA-608, CEA-708

Audio sampling

Broadcast standard - 48 kHz at 24-bit

SDI colour accuracy

RGB 8, 10, 12-bit 4:4:4 up to 4K DCI 30p and YUV 8, 10, 12-bit 4:4:4 and 4:2:2 in all modes

Weight

138g

Power consumption

~ 8.40W

Temperature range

Operating: 0 to 40°C
