Full size BNC connectors, standard height PCIe bracket only, no cables included
... learn more
Visuals Price
2,215.64 CHF VAT excl.

2,395.10 CHF Inc. VAT

Manufacturer price 2 332,25 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 2 to 3 weeks
  • In-store pickup
    • Available in 2 to 3 weeks

Full-size AJA BNC connectors, standard height PCIe bracket only
Increase your video and audio I/O capacity with the Corvid 44 BNC featuring 3G-SDI connectivity on full-size BNC connectors. Configure each SDI connection individually as input or output and mix formats for up to 4 HD or SD channels on a single card. As demand for higher resolutions increases, combine SDI connections into a single 4K/UHD channel, offering incredible flexibility and guaranteed future-proofing.




Specifications



Video formats

(4K) 4096 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
(UltraHD) 3840 x 2160p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
(2K) 2048 x 1080p 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
(2K) 2048 x 1080PsF 23.98, 24, 25, 29.97, 30, 48 A/B, 50 A/B, 59.94 A/B, 60 A/B
(HD) 1080p 23.98, 24, 25, 29.97, 30, 50 A/B, 59.94 A/B, 60 A/B
(HD) 1080PsF 23.98, 24, 25, 29.97, 30
(HD) 1080i 25, 29.97, 30
(HD) 720p 50, 50.94, 60
(SD) 625i 25
(SD) 525i 29.97

Digital video input

4 x 3G-SDI BNC

Digital video output

4 x 3G-SDI BNC

Digital audio input

16 channels 24-bit embedded SDI, 48 kHz synchronous

Digital audio output

16 channels 24-bit embedded SDI, 48 kHz synchronous

Dimensions (w x d x h)

0.727" × 6.6" × 2.713" (18.47 mm × 167.65 mm × 68.90 mm)

Weight

0.4 lb (0.2 kg)

Power

17 watts typical, 19 watts maximum

Environment

Airflow across card for fanless models



Full size BNC connectors, standard height PCIe bracket only, no cables included
