Astera - PixelBar Wireless Linear Wash Fixture (20")
Astera AX2-50 - PixelBar Wireless Linear Wash Fixture (20")
1048522
Built for versatility and high performance, the Astera AX2-50 PixelBar is a 20" long wireless linear wash fixture equipped with eight individually controllable pixels, 21° lenses from Gaggione, and the TITAN LED Engine, rendering it a highly capable LED bar for concerts, tours, corporate events, and more.
Visuals Price
959.30 CHF
VAT excl.
1,037.00 CHF Inc. VAT
Made to order
-
Delivery
-
Delivery time 5 to 8 weeks
Order now, we'll deliver as soon as possible.
Contact us for alternatives:
022 561 07 07.
-
Delivery time 5 to 8 weeks
-
In-store pickup
- Available in 5 to 8 weeks
Wireless Linear Wash PixelBar (20")
|
|
Specifications |
|
| LED Array | TITAN LED Engine | |
| Colours | RGB / Mint / Amber | |
| LED Power | 80 W | |
| Power Consumption | 40 W | |
| Luminous Flux | 1800 lumens at 2700 K 2230 lumens at 3200 K 2265 lumens at 5500 K |
|
| CRI Accuracy @ Ra | ≥96 (TLCI 3200 to 6500 K) | |
| Beam Angle | 21° | |
| Strobe | 0 to 25 Hz | |
| Pixels | 8 | |
| Battery Life | 70% after 300 cycles | |
| Battery Life | Up to 20 hours | |
| Charging Time | 5 hours (Nominal) | |
| Input Voltage | 100 to 240 V AC, 50/60 Hz, 2 A maximum | |
| DMX Connectors | 1 x 5-pin male XLR input 1 x 5-pin female XLR output |
|
| Receiver | Integrated CRMX Receiver | |
| Wireless Frequency Band | UHF: 917 to 922.20 MHz | |
| Modulation | FHSS | |
| Transmitter Power | <25 mW | |
| Number of Channels | 53 | |
| Wireless Range | 300 m / 984,3' | |
| Power Connections | 1 x powerCON TRUE1 input 1 x powerCON TRUE1 output |
|
| Operating Temperature | 0 to 40 °C / 32 to 104 °F | |
| IP Rating | IP65 | |
| Housing | Aluminium | |
| Dimensions | 52.1 x 16.5 x 6.6 cm / 20.5 x 6.5 x 2.6" (Hook included) 50.0 x 16.5 x 6.6 cm / 19.7 x 6.5 x 2.6" (Without hook) |
|
| Weight | 9.9 lb / 4.5 kg | |
Built for versatility and high performance, the Astera AX2-50 PixelBar is a 20" long wireless linear wash fixture equipped with eight individually controllable pixels, 21° lenses from Gaggione, and the TITAN LED Engine, rendering it a highly capable LED bar for concerts, tours, corporate events, and more.
