Sennheiser - XSW-D receiver with 6.3mm and male XLR outputs

Sennheiser XSW-D PEDALBOARD RX - XSW-D receiver with 6.3mm and male XLR outputs

1012101
4044155240658
Sennheiser XSW-D PEDALBOARD RX - XSW-D receiver with 6.3mm and male XLR outputs
Sennheiser XSW-D PEDALBOARD RX - XSW-D receiver with 6.3mm and male XLR outputs
XSW-D receiver with 6.3mm and male XLR outputs
... learn more
Visuals Price
226.44 CHF VAT excl.

244.79 CHF Inc. VAT

Manufacturer price 248,84 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Sennheiser XSW-D PEDALBOARD RX pedalboard receiver for XSW-D digital wireless system (2.4 GHz)
Part of the Sennheiser XSW-D digital wireless system, the XSW-D PEDALBOARD RX pedalboard receiver is available as an individual component for use as an additional or backup receiver, or as a replacement unit. It features a 6.35 mm instrument output for connecting to your amplifier or pedal, as well as a DI output on a balanced XLR connection. There is also a built-in tuner with LED display for visual confirmation, and a footswitch to mute your instrument when tuning.
The XSW-D delivers Sennheiser's world-renowned wireless sound quality in a miniaturised, low-latency, one-button digital system that anyone can use. Plug it in, switch it on, and you're immediately ready to play, simplifying your setup so you can focus on your performance with confidence.
Note: The preliminary specifications and characteristics of the pedalboard receiver are still subject to change.
Plug in, switch on: it works
- The 1-button, 1-LED concept with single-button interface and status indicator effortlessly handles power and pairing tasks for you - without requiring additional button presses.
(For optimal results, using the XSW-D is recommended in environments with limited Wi-Fi / 2.4 GHz traffic.)
Upgrade to Sennheiser sound quality
- Sennheiser wireless systems are an industry standard, prized by professionals for their clarity and reliability. The XSW-D system allows new users and budget-conscious customers to access true Sennheiser sound quality without breaking the bank.
- Analogue wireless systems must compress your signal to operate in the FM band, resulting in thin sound with high noise levels. The XSW-D uses digital technology to preserve your signal's dynamic range and deliver crisp, clear guitar sound with all the nuances of your performance.
- On stage, timing is crucial, and the XSW-D uses the aptX Live codec to deliver an impressive latency of just 3.9 ms, so you don't experience any lag when playing - keeping you in time and in the groove.
Easy 2.4 GHz digital wireless system
- Nothing ruins a take like hearing the weather forecast through your amp. Unlike traditional analogue wireless systems, the XSW-D digital system operates in the 2.4 GHz ISM band, protecting your signal integrity against interruptions and dropouts caused by TV channels, radios or other sources.
- Thanks to Sennheiser's channel allocation and interference management technology, the system selects the best operating frequency and automatically switches to a clean channel to ensure reliable transmission at distances up to 76.2 m line of sight.
Licence-free operation worldwide
- As the XSW-D system operates in the licence-free 2.4 GHz band, you don't have to worry about local licensing laws, frequency coordination and other technical hassles.
- Simply let the system choose a channel for you, and start playing - whether you're performing at home or anywhere in the world.
Other features
- Powered by the included mains adapter
- Mute function from transmitter or receiver
- Up to five systems can be used simultaneously in the same environment
- Multiple pairing allows you to quickly switch between multiple transmitters linked to one receiver (note that only one transmitter can broadcast to a receiver at a time)



Specifications



System



Frequency range

2.400 to 2.483 GHz

Latency

<4 ms with aptX Live codec

Transmission range

76.2 m (line of sight)

Simultaneous operation of units

Up to 5 systems simultaneously

Frequency response

10 Hz to 18 kHz

Signal-to-noise ratio

≥106 dB

THD

<0.1%

Modulation

GFSK with TDMA

Operating temperature

-10 to 55°C

Relative humidity

95% (non-condensing)

Receiver



Type

Pedalboard receiver

Output connector

Instrument: 6.35 mm TS, male
DI: XLR male

Audio output

Instrument: Consumer line level output, -12 dBu (maximum)
DI: Microphone level output

Power supply

Mains adapter

Dimensions

130 x 82 x 51 mm

Weight

Not specified by manufacturer

XSW-D receiver with 6.3mm and male XLR outputs
