Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER

1018227
4548736106611
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Sony UTX-B40/K42 - UHF SYNTHESIZED TRANSMITTER
Offering superb sound quality with digital processing, reliable RF transmission, true double tuner diversity reception and friendly features, the UWP-D series is an ideal partner for ENG (electronic news gathering) and EFP (electronic field production), as well as documentaries and weddings.
... learn more
Visuals Price
329.52 CHF VAT excl.

356.21 CHF Inc. VAT

Manufacturer price 346,86 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Sony SYNTHESISED UHF TRANSMITTER
The demand for high audio quality is increasing as high-resolution content becomes prevalent in the video production industry. Today's content creators face the challenge of capturing high-quality audio quickly, reliably and with limited resources.
Offering superb sound quality with digital processing, reliable RF transmission, true dual tuner diversity reception and user-friendly features, the UWP-D series is an ideal partner for ENG (electronic news gathering) and EFP (electronic field production), as well as documentaries and weddings.
- High-quality sound with Sony digital audio processing
- NFC SYNC function for quick and easy secure channel setting (IR synchronisation capability with URX-P03, URX-P03D and URX-S03D receivers)
- Volume control in automatic gain mode
- +15 dB volume boost mode for off-microphone audio
- Line input
- Transmitter frequency sent to receiver for pairing multiple receivers to one transmitter
- Variable audio cut function
- Compatibility with Sony WL-800/UWP/UWP-D series
- High-visibility OLED display, ideal for indoor/outdoor use
- USB connector for power supply
- Includes ECM-V1BMP lavalier microphone
Features
Digital audio processing for high-quality sound
Sony's advanced digital audio processing technology ensures high-quality sound with improved transient response performance. A new [optional] digital audio interface enables direct digital audio recording with many Sony professional camcorders and Alpha interchangeable lens cameras via the SMAD-P5 MI Multi Interface Shoe adapter, bypassing A/D and D/A conversion steps to guarantee excellent sound quality.
Quick and easy frequency setting
Sony's unique and user-friendly NFC SYNC function enables quick and intuitive secure channel setting between transmitter and receiver.
Lightweight and compact design
The reduced size and weight of the system enables superior mobility across a wide range of applications, including news reporting, documentaries, weddings and remote production. The compact size and low weight of the receiver makes it an ideal partner for use with small camcorders and interchangeable lens digital cameras.




Specifications



Oscillator type

Quartz PLL synthesiser

Antenna type

1/4 λ wavelength wire antenna

Carrier frequencies

638.025 MHz to 694.000 MHz (UHF-TV channels 42 to 48)

RF output power

30 mW/5 mW selectable

Capsule type

Electret condenser

Directivity

Omnidirectional

Input connector

3.5 mm diameter 3-pole lockable mini-jack

Reference audio input level

–60 dBV (MIC input, GAIN MODE set to NORMAL, 0 dB attenuation) +4 dBu (LINE input)

Audio attenuator adjustment range

0 dB to 27 dB (in 3 dB steps)

Frequency response

23 Hz to 18 kHz (typical)

Signal-to-noise ratio

60 dB (–60 dBV, 1 kHz input) 102 dB (GAIN MODE set to AUTO GAIN, max.) 96 dB (GAIN MODE set to NORMAL, max.)

Distortion

0.9% or less (–60 dBV, 1 kHz input)

Audio delay

Approximately 0.35 ms

Tone signal frequency

In UWP-D compander mode: 32.382 kHz In UWP compander mode: 32 kHz In WL800 compander mode: 32.768 kHz

Display

OLED

Power supply

DC 3.0 V (two LR6/AA alkaline batteries) DC 5.0 V (powered via USB Type-C connector)

Battery life*

Approximately 8 hours at 30 mW output power (measured with two Sony LR6/AA alkaline batteries at 25 °C (77 °F).)

Operating temperature

0 °C to 50 °C (32 °F to 122 °F)

Storage/transport temperature

–20 °C to +55 °C (–4 °F to +131 °F)

Dimensions

63 × 73 × 19 mm (2 1/2 × 2 7/8 × 3/4 in.) (W / H / D) (antenna not included)

Mass

Approximately 83 g (2.9 oz) (batteries not included)



Offering superb sound quality with digital processing, reliable RF transmission, true double tuner diversity reception and friendly features, the UWP-D series is an ideal partner for ENG (electronic news gathering) and EFP (electronic field production), as well as documentaries and weddings.
