Sennheiser - AVX Camera Receiver

Sennheiser EKP-AVX-3-EU - AVX Camera Receiver

111974
4044155086201
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
Sennheiser EKP-AVX-3-EU - AVX Camera Receiver
The EKP AVX is the ultra compact receiver for the AVX wireless microphone system. It plugs directly into the XLR audio input of your camera or recording device. The EKP can also be connected to DSLRs with the included minijack adaptor.
... learn more
Visuals Price
403.23 CHF VAT excl.

435.89 CHF Inc. VAT

Manufacturer price 443,11 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Sennheiser AVX camera receiver
The EKP AVX is the receiver for the AVX wireless microphone system. It features auto-configuring digital transmission that eliminates the tedious radio frequency adjustments. The ultra-compact receiver pivots around the XLR connector to avoid any collision with other devices mounted on your camera. It switches on and off automatically with your camera, thereby saving battery life. The AVX automatically adapts to your camera's input sensitivity without having to adjust the audio level on the microphone.
- Very quick setup
- Connects directly to the XLR audio input
- Ultra-compact receiver
- On/off via P48 phantom power
- Optimised dynamic range
- Automatic frequency management
- AES 256 encryption
.- Licence-free
- Metal housing
- Made in Germany




Specifications



Audio input

3.5 mm mini-jack

Audio output

XLR

Audio output level

-30 dBu - 0 dBu in 4 steps

Battery specifications

Li-Ion 3.7 V DC

Dynamic range

> 120 dB(A)

Frequency band

1880 - 1900 MHz

Frequency response

20 Hz - 20000 Hz

Modulation

GFSK

Operating temperature

-10 °C - +55 °C

Battery life

> 4h (Receiver), typ. 15 h (Transmitter with LiIon battery)

RF output power

adaptive up to 250 mW (peak) depending on country

Sampling rate

24 bit / 48 kHz

Signal-to-noise ratio

> 90 dB(A)

THD, total harmonic distortion

typ. 0.1%

Weight

Receiver: 87 g (with battery)

Latency

19 ms



The EKP AVX is the ultra compact receiver for the AVX wireless microphone system. It plugs directly into the XLR audio input of your camera or recording device. The EKP can also be connected to DSLRs with the included minijack adaptor.
