Laowa - 105mm f/2 STF Lens
Laowa VE10520P - 105mm f/2 STF Lens
1028566
6940486700107
Designed to provide a wealth of control over out-of-focus quality and to enhance bokeh, the Laowa 105mm f/2 Smooth Trans Focus Lens from Venus Optics is a short telephoto prime designed for full-frame Pentax K-mount cameras.
Visuals Price
1,043.00 CHF
VAT excl.
1,127.48 CHF Inc. VAT
Made to order
-
Delivery
- Shipped in 2 to 3 weeks
-
In-store pickup
- Available in 2 to 3 weeks
Laowa 105mm f/2 STF Lens
Designed to offer excellent control over the quality of background blur and to enhance bokeh, the Laowa 105mm f/2 Smooth Trans Focus lens from Venus Optics is a short telephoto lens designed for full-frame Pentax K cameras. The unique optical design incorporates an apodisation (APD) element, as well as two separate aperture diaphragms — 8 and 14 blades — allowing separate adjustment of bokeh as well as exposure and depth of field. This APD element functions as a radial graduated neutral density filter and, as such, limits light transmission to a T-stop value of 3.2, whilst allowing the depth of field and selective focus qualities of a true f/2 design.
In addition to the unique attributes of the APD element, the lens also incorporates three low-dispersion elements and one extra-low dispersion element to control chromatic aberrations and colour fringing, as well as to produce excellent overall sharpness and clarity. The lens is also characterised by its manual focus and manual aperture design, which offers excellent control over focus and exposure to optimise the use of the APD element.
Features
- Short telephoto lens designed for full-frame Pentax K cameras; this lens can also be used on APS-C models where it provides an equivalent focal length of 157.5 mm.
- The optical design incorporates an apodisation element that helps improve bokeh quality. This element, which resembles a radial graduated ND filter that fades from the centre towards the edges, produces more circular out-of-focus areas for more pleasing selective focus and shallow depth of field effects.
- To control the effect of the apodisation element, two separate aperture diaphragms are integrated into the lens design: a 14-blade diaphragm that works primarily in conjunction with the APD element to control bokeh, as well as a standard 8-blade diaphragm at the rear of the lens to control overall light transmission and affect depth of field.
- Due to the incorporation of the APD element, the lens offers an effective light transmission value of T3.2, whilst the f/2 designation relates primarily to the selective focus potential and depth of field control.
- Beyond the APD element, the lens also includes three low-dispersion elements and one extra-low dispersion element, which combine to limit chromatic aberrations across the entire aperture range and contribute to a high degree of sharpness and clarity.
- A manual focus design allows precise control for focusing down to 90 cm with a maximum magnification of 0.16x.
- Two manual aperture rings allow you to adjust both the diaphragm affecting exposure and the aperture affecting the APD.
Designed to offer excellent control over the quality of background blur and to enhance bokeh, the Laowa 105mm f/2 Smooth Trans Focus lens from Venus Optics is a short telephoto lens designed for full-frame Pentax K cameras. The unique optical design incorporates an apodisation (APD) element, as well as two separate aperture diaphragms — 8 and 14 blades — allowing separate adjustment of bokeh as well as exposure and depth of field. This APD element functions as a radial graduated neutral density filter and, as such, limits light transmission to a T-stop value of 3.2, whilst allowing the depth of field and selective focus qualities of a true f/2 design.
In addition to the unique attributes of the APD element, the lens also incorporates three low-dispersion elements and one extra-low dispersion element to control chromatic aberrations and colour fringing, as well as to produce excellent overall sharpness and clarity. The lens is also characterised by its manual focus and manual aperture design, which offers excellent control over focus and exposure to optimise the use of the APD element.
Features
- Short telephoto lens designed for full-frame Pentax K cameras; this lens can also be used on APS-C models where it provides an equivalent focal length of 157.5 mm.
- The optical design incorporates an apodisation element that helps improve bokeh quality. This element, which resembles a radial graduated ND filter that fades from the centre towards the edges, produces more circular out-of-focus areas for more pleasing selective focus and shallow depth of field effects.
- To control the effect of the apodisation element, two separate aperture diaphragms are integrated into the lens design: a 14-blade diaphragm that works primarily in conjunction with the APD element to control bokeh, as well as a standard 8-blade diaphragm at the rear of the lens to control overall light transmission and affect depth of field.
- Due to the incorporation of the APD element, the lens offers an effective light transmission value of T3.2, whilst the f/2 designation relates primarily to the selective focus potential and depth of field control.
- Beyond the APD element, the lens also includes three low-dispersion elements and one extra-low dispersion element, which combine to limit chromatic aberrations across the entire aperture range and contribute to a high degree of sharpness and clarity.
- A manual focus design allows precise control for focusing down to 90 cm with a maximum magnification of 0.16x.
- Two manual aperture rings allow you to adjust both the diaphragm affecting exposure and the aperture affecting the APD.
|
|
Specifications |
|
|
Focal length |
105 mm |
|
|
Maximum aperture |
f/2 |
|
|
Minimum aperture |
f/22 |
|
|
Lens mount |
Pentax K |
|
|
Format compatibility |
Full frame |
|
|
Angle of view |
23° 16' |
|
|
Minimum focusing distance |
2.95' / 90 cm |
|
|
Maximum magnification |
0.16x |
|
|
Optical design |
11 elements in 8 groups |
|
|
Aperture blades |
8 |
|
|
Focus type |
Manual focus |
|
|
Image stabilisation |
None |
|
|
Filter diameter |
67 mm (front) |
|
|
Dimensions (ø x L) |
2.99 x 3.89" / 76 x 98.9 mm |
|
|
Weight |
1.64 lb / 745 g |
Designed to provide a wealth of control over out-of-focus quality and to enhance bokeh, the Laowa 105mm f/2 Smooth Trans Focus Lens from Venus Optics is a short telephoto prime designed for full-frame Pentax K-mount cameras.
