Contrik MRM12 - Cable connector housing

1029601
Contrik MRM12 - Cable connector housing
Contrik MRM12 - Cable connector housing
Cable connector housing incl. chuck type strain relief and bushing for male and female inserts
... learn more
Visuals Price
13.13 CHF VAT excl.

14.19 CHF Inc. VAT

Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Contrik cable connector housing
The miniCON with its flexible and compact design is perfectly suited for multipole/industrial applications. The robust all-metal miniature connector features a push-pull locking device and is distinguished by an excellent cost/performance ratio.
Features
- Easy assembly: Soldering contacts in disassembled condition avoids difficult wiring of high-density contacts.
- Velvet chrome housing
- Push-pull self-locking system
- Robust all-metal construction precision-machined
- Gold-plated contacts




Specifications



Connection type

miniCON

Gender

male

Contact resistance

≤ 8 mΩ

Dielectric strength

1 kVdc

Insulation resistance

> 0.5 GΩ

Rated current per contact

3 A

Rated voltage

< 50 V

Insertion force

< 25 N

Cable section

0.5 mm²

Cable section

20 AWG

Wiring

Solder contacts

Locking device

Push-Pull

Mounting direction

Rear mounting

Housing shape

14.10 mm

Contact plating

0.2 µm AuCo

Contacts

Brass (CuZn35Pb2)

Insert

Polyamide (PA 6.6)

Shell

Die-cast Zamak (ZnAl4Cu1)

Flammability

UL 94 V-0

Protection class

IP 5X

Solderability

Compliant with IEC 68-2-20

Temperature range

-30 °C to +80 °C



Cable connector housing incl. chuck type strain relief and bushing for male and female inserts
