This ultra-efficient light panel has 504 full-color RGBW (2700K-7500K) LEDs that emit 600W equivalent light, respectively 5759 LUX / 1m with an extremely low power consumption of only 60W.
... learn more
Visuals Price
720.63 CHF VAT excl.

779.00 CHF Inc. VAT

Made to order

Nanlite MixPanel 60
The Nanlite MixPanel 60 RGBWW LED panel is a 17 x 14 x 3" fixture capable of switching between a multi-traditional LED panel for hard light, a diffused SMD LED panel for soft light, and an adjustable RGB panel for colored and creative effects at the touch of a button. The MixPanel features a wide CCT range from 2700 to 7500 to seamlessly integrate into any ambient light situation, match other fixtures, or simply for creative expression. The panel's high CRI/TLCI ratings of 98/95 are indicators of advanced color rendering accuracy. It's also possible to adjust the magenta/green balance for greater precision, as well as adjust light intensity from 0 to 100% for more versatility.
One of the MixPad's advanced features is RGB mode which uses its 4-in-1 LEDs to access literally over 16 million different color combinations for optimal choice. The fixture also features a Boost mode. Using the fixture in normal mode, the MixPanel 60 produces 4980 lux at 3.28' and 5600K. When switched to Boost mode, the output rises to 6600 lux. Additionally, with 100% to 0% dimming, you can quickly adapt the MixPanel 60 to any scene without adding ND filters or diffusion. Another benefit is a built-in library of 43 gels that provides five CTO, five CTB, and thirty-three Calcolor choices. Furthermore, the fixture has nine special effects that include Hue Loop, CCT Loop, Flash, Pulse, Storm, Siren, TV, Paparazzi, and Candle/Fire.
The MixPanel 60 is ready for worldwide use thanks to its 100 to 240 VAC adapter, but it will also run on optional batteries via its V-mount plate.
Three Light Sources in One
The Nanlite MixPanel series can switch, at the touch of a button, between a multi-traditional LED panel for hard light, a diffused SMD LED panel for soft light, and an adjustable RGB panel for colored and creative effects.
Impressive Light Output
Using the fixture in normal mode, the MixPanel 60 produces 4980 lux at 3.28' and 5600K. When switched to Boost mode, the output rises to 6600 lux. Additionally, with 100% to 0% dimming, you can quickly adapt the MixPanel 60 to any scene without adding ND filters or diffusion.
Exceptional Color
Lighting brightness is important, but without color accuracy, a lot of time and money can be lost in post-production. The MixPanel features a CRI of 98, TLCI of 95, and green/magenta adjustment in CCT mode, meaning you can be confident in the accuracy of color reproduction.
Intuitive User Interface
the MixPanel's operating system has been developed from the ground up to be efficient and intuitive to use. Additionally, you can save your settings as presets to customize your lighting and make it consistent and reproducible.
Gel Emulation and Practical Effects
The MixPanel's gel emulation mode provides a selection of 43 gel presets in two light sources (3200 and 5600K) which includes five CTO, five CTB, and 33 Calcolor filters. Additionally, nine pre-programmed and adjustable special effects allow for mimicking lighting scenarios such as Hue Loop, CCT Loop, Flash, Pulse, Storm, Siren, TV, Paparazzi, and Candle/Fire.
Power Anywhere
Optimized for studio or outdoor use, the MixPanel can operate either with the included multi-voltage AC adapter or optional V-mount batteries, allowing for use in any location regardless of power availability.




Specifications



Fixture



Color Temperature

2700 to 7500K

Color Accuracy Standard

CRI 98
TLCI 95

Cooling System

Passive

Dimming

Yes, 0 to 100%

Lumens

5808 (at 7500K)

Photometrics

5600K:
462.6 fc / 4980 lux at 39.37" / 1 m

Fixture Dimensions

Flood: 17.0 x 14.0 x 3.0" / 43.2 x 35.6 x 7.6 cm

Fixture Weight

7.3 lb / 3.31 kg (Yoke included)

Connectors



Battery Plate

1 x V-Mount

Mounting



Fixture Mounting

5/8" Receiver

Yoke



Yoke Type

Yoke/Mount

Power



AC Input Power

100 to 240 VAC, 50 / 60 Hz

DC Input Power

15 VDC at 6 A

Power Source

AC Adapter, External Battery

Maximum Power Consumption

60 W
