Sonnet - Tempo SSD RAID 0/1, for (2) SATA 2.5 inches SSD
Sonnet FUS-SSD-2RAID-E - Tempo SSD RAID 0/1, for (2) SATA 2.5 inches SSD
1023766
Tempo SSD RAID 0/1, for (2) SATA 2.5 inches SSD, max. 1000 MB/Sec., PCIe 2.0 x2
Visuals Price
109.16 CHF
VAT excl.
118.00 CHF Inc. VAT
Made to order
-
Delivery
- Shipped in 2 to 3 weeks
-
In-store pickup
- Available in 2 to 3 weeks
Sonnet Tempo SSD Raid 0/1, For (2) Sata 2.5 Inches SSD
Install Two 2.5-inch SATA SSDs into a PCIe Card Slot
If you need faster, high-capacity internal storage for your desktop computer or server, 2.5-inch SATA SSDs are the cost-effective choice. Sonnet's Fusion Dual 2.5-inch SSD RAID PCIe card enables you to upgrade your system in a flash, mounting one or two SSDs with up to 8TB capacity in a single full-length PCIe card slot, with no power or data cables, adapters, or mounting trays required.
Great 2-Drive Hardware RAID 0 Performance
Install the Sonnet Fusion card into a PCIe 3.0 slot of a computer or Thunderbolt 3 expansion system and achieve great transfer speeds up to 1000 MB/s.
Disk Striping
Increases performance by interleaving data into blocks (stripes) across two or more drives simultaneously to increase speed.
Fast RAID 1 Performance
Looking for the safety of a simultaneous backup? RAID 1 performance of up to 560 MB/s may be obtained with any compatible computer or expansion system.
100% Redundancy
If primary drive crashes, the mirrored drive will automatically replace the primary drive.
Features
Add up to 8TB of SSD Storage
Mounts two cost-effective 2.5-inch SATA SSDs in a full-length PCIe slot.
Great SSD Performance
Supports data transfers speeds up to 1000 MB/s.
Onboard Hardware RAID Controller
Supports RAID 0, RAID 1, Span, and JBOD configurations in macOS, Windows, and Linux.
USB 3.2 Gen 2 USB-C Port
Includes SuperSpeed USB-C 10Gbps port to connect a fast external drive.
Great USB Performance
Supports data transfers speeds up to 1000 MB/s.
Power for Peripherals
Supports a USB bus-powered SSD, SSD RAID, or hard drive device with up to 15W power.
Optimized for Thunderbolt
Use in Sonnet Thunderbolt expansion systems at full performance.
Mac, Windows & Linux Compatible
Supports Mac, Windows, and Linux computers with PCIe 3.0 slots.
Compatibility
Mac Compatibility
- Mac Pro 5,1 (Mid 2010 & Mid 2012) with available full-length PCIe slot
- Mac Pro 7,1 (2019)
- macOS 10.12.6+(4)
- macOS Catalina compatible
Windows Compatibility
- Computer with available full-length, full-height PCIe slot (PCIe 3.0 slot is preferred)
- Windows 10, 8.1, 7
- Windows Server 2016, 2012, 2008 (64-bit editions)
Linux Compatibility
- Computer with available full-length, full-height PCIe slot (PCIe 3.0 slot is preferred)
- Linux Kernel 5.0+
Thunderbolt Compatibility
- Mac computer with Thunderbolt 2 or Thunderbolt 3 ports via a Thunderbolt 2 or 3 to PCIe card expansion system with available full-length PCIe slot
- Windows computer with Thunderbolt 3 ports via a Thunderbolt 3 to PCIe card expansion system with available full-length PCIe slot
- Linux computer with Thunderbolt 2 or Thunderbolt 3 ports via a Thunderbolt 2 or 3 to PCIe card expansion system with available full-length PCIe slot
Install Two 2.5-inch SATA SSDs into a PCIe Card Slot
If you need faster, high-capacity internal storage for your desktop computer or server, 2.5-inch SATA SSDs are the cost-effective choice. Sonnet's Fusion Dual 2.5-inch SSD RAID PCIe card enables you to upgrade your system in a flash, mounting one or two SSDs with up to 8TB capacity in a single full-length PCIe card slot, with no power or data cables, adapters, or mounting trays required.
Great 2-Drive Hardware RAID 0 Performance
Install the Sonnet Fusion card into a PCIe 3.0 slot of a computer or Thunderbolt 3 expansion system and achieve great transfer speeds up to 1000 MB/s.
Disk Striping
Increases performance by interleaving data into blocks (stripes) across two or more drives simultaneously to increase speed.
Fast RAID 1 Performance
Looking for the safety of a simultaneous backup? RAID 1 performance of up to 560 MB/s may be obtained with any compatible computer or expansion system.
100% Redundancy
If primary drive crashes, the mirrored drive will automatically replace the primary drive.
Features
Add up to 8TB of SSD Storage
Mounts two cost-effective 2.5-inch SATA SSDs in a full-length PCIe slot.
Great SSD Performance
Supports data transfers speeds up to 1000 MB/s.
Onboard Hardware RAID Controller
Supports RAID 0, RAID 1, Span, and JBOD configurations in macOS, Windows, and Linux.
USB 3.2 Gen 2 USB-C Port
Includes SuperSpeed USB-C 10Gbps port to connect a fast external drive.
Great USB Performance
Supports data transfers speeds up to 1000 MB/s.
Power for Peripherals
Supports a USB bus-powered SSD, SSD RAID, or hard drive device with up to 15W power.
Optimized for Thunderbolt
Use in Sonnet Thunderbolt expansion systems at full performance.
Mac, Windows & Linux Compatible
Supports Mac, Windows, and Linux computers with PCIe 3.0 slots.
Compatibility
Mac Compatibility
- Mac Pro 5,1 (Mid 2010 & Mid 2012) with available full-length PCIe slot
- Mac Pro 7,1 (2019)
- macOS 10.12.6+(4)
- macOS Catalina compatible
Windows Compatibility
- Computer with available full-length, full-height PCIe slot (PCIe 3.0 slot is preferred)
- Windows 10, 8.1, 7
- Windows Server 2016, 2012, 2008 (64-bit editions)
Linux Compatibility
- Computer with available full-length, full-height PCIe slot (PCIe 3.0 slot is preferred)
- Linux Kernel 5.0+
Thunderbolt Compatibility
- Mac computer with Thunderbolt 2 or Thunderbolt 3 ports via a Thunderbolt 2 or 3 to PCIe card expansion system with available full-length PCIe slot
- Windows computer with Thunderbolt 3 ports via a Thunderbolt 3 to PCIe card expansion system with available full-length PCIe slot
- Linux computer with Thunderbolt 2 or Thunderbolt 3 ports via a Thunderbolt 2 or 3 to PCIe card expansion system with available full-length PCIe slot
|
|
Specifications |
|
|
Hardware |
|
|
|
Form Factor |
Full-height, full-length PCIe card |
|
|
Bus Interface |
PCI Express 3.0 x4 |
|
|
Internal Connectors |
Two SATA for 2.5-inch SSDs |
|
|
External Connector |
One USB-C port (10Gbps USB 3.2 Gen 2) |
|
|
SSDs Supported |
SATA 6 Gb/s |
|
|
Boot Support |
No |
|
|
Supported Drive Configurations |
RAID 0 RAID 1 Span JBOD |
|
|
S.M.A.R.T. Status Data Reporting Support |
No |
|
|
USB-C Port |
|
|
|
Peripherals Supported |
Industry standard USB 3.2 Gen 1, 2 & 2x2, USB 3.1 Gen 1& 2, USB 3.0, 2.0, and 1.1 Thunderbolt 3-only peripherals are NOT supported |
|
|
Bus-powered Peripherals Supported |
HD, SSD, SSD RAID 3.0A advertised using USB CC (Channel Configuration) Up to 15W for operation or charging |
|
|
Cables Supported |
USB-C 10Gbps USB-C 5Gbps Thunderbolt 3 40Gbps (0.5- and 0.7-meter only) Thunderbolt 3 20Gbps |
|
|
USB Chipset |
ASMedia 3142 ASMedia 1352R |
|
|
USB Standard |
Complies with OHCI (Open Host Controller Interface), EHCI (Enhanced Host Controller Interface), and xHCI (eXtensible Host Controller Interface) standards |
|
|
UASP |
USB attached SCSI protocol supported under macOS 10.12+, Windows 10 |
|
|
Number of Devices Supported |
Up to 31 |
|
|
Hot Plug |
Supports hot-pluggable and hot swappable device connection |
|
|
Boot Support |
No computers support booting at this time |
|
|
RoHS Compliant |
Yes |
