Kramer KT-107 - 7-Inch Wall & Table Mount PoE Touch Panel
1011004
7-Inch Wall & Table Mount PoE Touch Panel
Visuals Price
1,796.05 CHF
VAT excl.
1,941.53 CHF Inc. VAT
Manufacturer price 2 113,00 CHF VAT excluded
Made to order
-
Delivery
- Shipped in 1 to 2 weeks
-
In-store pickup
- Available in 1 to 2 weeks
Kramer 7-Inch PoE Touch Panel for Wall and Desk Mounting
The KT-107 is a powerful 7-inch multi-touch IPS touch panel with 1280x800 resolution. Elegantly designed for decorative integration in the room, this portable touch panel can be deployed on a table or wall, mounted in standard wall junction boxes. The KT-107 supports wired Power over Ethernet (PoE) and advanced Wi-Fi connectivity options. The touch panel comes with table and wall mounting brackets, USB cable and power supply unit for easy installation, with elegant cabling and secure mounting, reliable operation and flexible deployment. The KT-107 is an Android-based touch panel ideal for any Kramer 24/7-supported commercial AV or control application and features a fully customisable and user-friendly graphical user interface configured by Kramer software. The Wi-Fi 5GHz band frequency range of the KT-107RB is limited to a maximum of 5.35GHz.
- Elegant Design - Seamless integration with room furniture design, whether on a table or wall, with flexible cabling and panel locking options.
- Superior User Experience - High-resolution 1280x800 IPS display with wide viewing angles of ±80° horizontal and vertical, integrated brightness sensor for auto-adaptive brightness, with advanced 10-point multi-touch and 2-finger gesture capabilities.
- Powerful Processing - Processing performance with quad-core CPU, GPU, 2GB RAM, 16GB ROM, smoothly running complex graphics-rich multimedia applications, such as H.265 video and audio stream encoding and decoding, and smooth operations of high-resolution 2Mp HD front camera.
- Flexible Services - Advanced Android 6.0 operating system with Kramer-rich and market-available applications from cloud/store offerings, such as K-Touch control and EventBoard scheduling applications.
- Easy Installation - Power and connectivity via a single Ethernet cable.
- Flexible Mounting - Including table and wall brackets that fit commercially available 2-gang wall junction boxes.
- Optional Connectivity - Simple BTLE 4.0 wireless Bluetooth as well as connection to USB peripherals for table or wall installations, using the included USB cable.
- Reliable Network - Seamless switching between wired and 802.11ac wireless connectivity.
- Versatile Power Options - PoE, PSU and battery.
- Auto-Detection - Optimised performance and operation according to automatically detected LAN speed.
- Firmware Update - Via USB port.
- Secure Deployment - Flexible locking options to prevent unwanted removal from panel mounting, elegantly designed to remain out of sight.
- Secure Operation - Highly secure operation of applications such as password-protected exit, hidden control buttons, etc. Red LED alert when camera is active.
Applications
- Control interface in meeting and conference rooms, boardrooms and auditoriums
- Room scheduling presentation
|
|
Specification |
|
|
DESKTOP MOUNTING PORTS |
1 Ethernet 1000/100/10BaseT on RJ–45 connector, 1 micro USB 2.0, 2-pin terminal block for DC power |
|
|
WALL MOUNTING PORTS |
1 Ethernet 1000/100/10BaseT on RJ–45 connector, 2-pin terminal block for DC power |
|
|
SPEAKERS |
2x1W, 8Ω |
|
|
MICROPHONE |
Sensitivity of –42dB ±3dB @1kHz |
|
|
CPU PERFORMANCE |
Quad Core 1.6GHz, GPU, 2GB RAM, 16GB flash |
|
|
OS SOFTWARE |
Android 6.0.1 |
|
|
MULTI-TOUCH |
10-point, 2-finger gesture |
|
|
DISPLAY |
IPS 7", 1280x800 RGB pixels, 16:10 aspect ratio, horizontal/vertical viewing angles of ±85°, brightness of 400cd/m2, contrast ratio of 800:1 |
|
|
VIDEO DECODING FORMAT |
HEVC/H.265, H.264, H.263, MPEG–1/2/4, VC–1, VP6/8, RV8/9/10, AVS, MVC, Sorenson Spark, M–JPEG |
|
|
VIDEO ENCODING FORMAT |
H.264, MVC, VP8, M–JPEG |
|
|
ETHERNET PORT |
PoE LAN 10/100/1000Mbps |
|
|
WIRELESS COMMUNICATION |
Wi–Fi 802.11 b/g/n/ac, Bluetooth 4.0 KT–107RB — The 5GHz band frequency range is limited to a maximum of 5.35GHz |
|
|
CAMERA |
Front-facing, 2M pixels, HD 720p |
|
|
BATTERY |
Rechargeable, supports up to 3 hours of Wi-Fi operation |
|
|
CONTROLS |
Hidden reset button, power button (ON/OFF), volume + button Touch panel status LED: flashing green during charging, solid green when fully charged, red when camera is on |
|
|
POWER INPUTS |
Power over Ethernet (IEEE802.3af and IEEE802.3at PoE compliant), power supply unit |
|
|
POWER CONSUMPTION |
5V DC, 3A |
|
|
OPERATING TEMPERATURE |
0° to +40°C (32° to 104°F) |
|
|
STORAGE TEMPERATURE |
–10° to +55°C (14° to 131°F) |
|
|
HUMIDITY |
10% to 90%, non-condensing RH |
|
|
ENCLOSURE DESIGN |
Black enclosure and cover |
|
|
CERTIFICATION |
CE/CB, FCC, ROHS, REACH |
|
|
MOUNTING OPTIONS |
Desktop (with docking station), wall mounting (with mounting unit and panel mounting plate) |
|
|
INCLUDED ACCESSORIES |
Mains adapter (5V, 4.0A AC/DC), table stand, wall mounting unit, panel mounting plate, angled USB OTG cable, installation screws |
|
|
OPTIONS |
Wall security lock (KT–107–OWLK) |
|
|
PRODUCT DIMENSIONS |
17.80cm x 13.00cm x 1.30cm (7.01" x 5.12" x 0.51") W, D, H |
|
|
PRODUCT WEIGHT |
0.4kg (0.8lbs) approx. |
