Datavideo - 10.1 inches 4RU Rack mount Dual monitors
Datavideo 2100-0102 - TLM-102 - 10.1 inches 4RU Rack mount Dual monitors
1,233.83 CHF Inc. VAT
-
Delivery
- Shipped in 2 to 3 weeks
-
In-store pickup
- Available in 2 to 3 weeks
The Datavideo 10" IPS LCD dual monitor is a rack-mountable control unit designed for broadcasting, video production and audiovisual professionals. The monitors feature vectorscope, waveform and video signal converter functions. Each has a 3G/HD/SD-SDI input and an HDMI input, with loop-through outputs for both. The built-in cross conversion allows each monitor to use one input for display and the other for conversion. The 4RU rack design provides a mounting solution for on-site monitoring, monitor walls and production control rooms.
Features:
– IPS screen with 1280 x 800 resolution
– Dual monitor
– 4RU rack mounting
– Compatible with 3G-SDI and HDMI video inputs with loop-through output
– Bars (YRGB image), Timecode, Waveform, Vectorscope, Audio VU Meter, Edge Enhancement, Zoom, Pixel-to-Pixel, Underscan, Image Control
– SDI/HDMI cross conversion
– Individual adjustment of brightness, contrast, colour saturation and LED backlight level for each monitor
– Colour temperature adjustment
– Front panel headphone jacks
– User-programmable function buttons (F1, F2)
|
|
Specifications |
|
|
Screen Size |
10" (25.4 cm) |
|
|
Screen Type |
Dual LCD screen, IPS panel |
|
|
Resolution |
1280 x 800 |
|
|
Viewing Angle (H/V) |
170°/170° |
|
|
Brightness |
300 cd/m2 |
|
|
Contrast Ratio |
800:1 |
|
|
Rack Mounting |
4 RU |
|
|
Video Inputs |
1 x 3G/HD/SD-SDI 1 x HDMI |
|
|
Video Outputs |
1 x 3G/HD/SD-SDI, loop-through output 1 x HDMI, loop-through output |
|
|
Audio Input/Output |
Embedded audio via SDI and HDMI Headphone jack |
|
|
Supported Input Resolutions |
1080p 23.98/24/25/29.97/30/50/59.94/60 1080i 50/59.94/60 720p 23.98/24/25/29.97/30/50/59.94/60 480i (NTSC) 576i (PAL) |
|
|
Image Format |
16:9, 4:3 |
|
|
Special Functions |
Timecode, Waveform, Vectorscope, Audio VU Meter, Edge Enhancement, Zoom, Pixel-to-Pixel, Underscan, SDI/HDMI Cross Conversion |
|
|
Tally LED Indicator |
On Air (Red) Ready (Green) |
|
|
Power Requirements |
12 VDC, 26 W |
