Kramer DK42DU-N(CPN11433) - Dual-Head KVM Switch 4-Port DVI-I video, w/fUSB

1010955
Kramer DK42DU-N(CPN11433) - Dual-Head KVM Switch 4-Port DVI-I video, w/fUSB
Kramer DK42DU-N(CPN11433) - Dual-Head KVM Switch 4-Port DVI-I video, w/fUSB
Dual-Head KVM Switch 4-Port DVI-I video, w/fUSB
... learn more
Visuals Price
935.85 CHF VAT excl.

1,011.65 CHF Inc. VAT

Manufacturer price 1 101,00 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Kramer 4-port dual-screen DVI-I video KVM switch, with fUSB
The DK42DU-N is a 4-port, dual-screen DVI-I, 4K30 UHD KVM switch. It enables users to share peripherals - keyboard, video, mouse, audio and USB - between four networks/computers. It also allows a USB port to be assigned to a specific computer whilst switching other peripherals, for example when a USB smart card reader must remain mapped to a certain computer.
- 4K30 UHD resolution — Supports resolutions up to 3840×2160 @30Hz.
- Extended/duplicated display support — Enables switching of keyboard, mouse and up to 2 displays (extended or duplicated) between computers.
- Multi-screen support — Switch to KM mode to allow keyboard and mouse control switching between computers, when each computer is connected to up to 4 displays (extended or duplicated).
- USB freeze — Assign the USB port to a specific computer whilst switching keyboard, video, mouse and audio
peripherals between other computers. Useful when a USB peripheral such as a USB flash drive must remain mapped to a certain computer, whilst the user works on another computer.
- Audio freeze — Assign the audio port to a specific computer whilst switching keyboard, video, mouse and USB peripherals between other computers. Useful in scenarios where a user needs to listen to audio from one computer whilst working on another computer.
- USB 3.0 Super Speed port — Transfer data and files between peripherals and computers at USB 3.0 Super Speed via the KVM switch's USB 3.0 ports.
- Fast USB charging — Quickly charge USB devices connected to high-power USB ports.
- Copy & Paste — Transfer text and files between all computers connected to the KVM switch (no network connection is required between the parties). Use standard keyboard shortcuts to copy and paste (CTRL+C / CTRL+V) or context menu commands.
Applications
- Government agencies
- Military
- Financial institutions



Specifications



Console ports

2 DVI-I connectors (single link/dual link)

2 USB-A connectors for keyboard and mouse

4 USB-A 3.0 connectors for USB peripherals

1 3.5mm mini-jack for unbalanced stereo audio

1 3.5mm mini-jack for microphone

1 RJ-45 connector for control (RDC)

Computer ports

8 DVI-I connectors (single link/dual link)

4 USB-B connectors for keyboard and mouse

4 USB-B 3.0 connectors for USB peripherals

4 3.5mm mini-jacks for unbalanced stereo audio

4 3.5mm mini-jacks for microphone

Maximum resolution

4K30 UHD: 3840X2160 @30Hz via DVI to HDMI cable

DVI dual link: 2560X1600 @60Hz via DVI cable

Power consumption

12V DC, 1.5A

AC input

100 to 240V AC

Power supply type

External

Operating temperature

0° to 40°C (32° to 104°F)

Storage temperature

–20° to 60°C (–4° to 140°F)

Humidity

0–80% RH, non-condensing

Supported operating systems

Windows, Linux, Mac

Product certification

CE, RCM, FCC Class B, VCCI, TUV US, TUV Canada
