PreSonus - 5-Port AVB Switch with PoE
PreSonus SW5E - 5-Port AVB Switch with PoE
1029043
0673454006449
The PreSonus SW5E is a rugged AVB network switch, designed to connect digital audio devices over long distances using CAT5e or CAT6 Ethernet cable. The device provides Power over Ethernet (PoE) and allows for the routing of audio anywhere on the network with extremely low latency.
Visuals Price
407.61 CHF
VAT excl.
440.63 CHF Inc. VAT
Made to order
-
Delivery
- Shipped in 1 to 2 weeks
-
In-store pickup
- Available in 1 to 2 weeks
PreSonus 5-port AVB switch with PoE
The PreSonus SW5E is a robust AVB network switch designed to connect digital audio devices over long distances using CAT5e or CAT6 Ethernet cables. The device provides Power over Ethernet (PoE) and enables audio routing anywhere on the network with extremely low latency. The AVB protocol provides a high-precision clock that significantly reduces harmonic distortion and phase shift, ensuring audio remains clean and clear. PoE allows network cables to carry electrical power to compatible devices, providing both network data, such as digital audio, and electrical power from a single cable. Four of the SW5E's five ports provide PoE, with the fifth port used for networking with additional switches to create a larger network. The robust metal housing is designed to withstand the rigours of road wear and can be rack-mounted using an optional rack tray. The PreSonus SW5E comes with a standard IEC power cord. Ports and indicators - 5 AVB Ethercon sockets - 4 ports with PoE - PoE power indicators - Network link/activity indicators Switches and power - PoE power on/off - Internal power supply with IEC connector Physical characteristics - Robust metal chassis - Rack mountable (screws onto a rack tray)
The PreSonus SW5E is a robust AVB network switch designed to connect digital audio devices over long distances using CAT5e or CAT6 Ethernet cables. The device provides Power over Ethernet (PoE) and enables audio routing anywhere on the network with extremely low latency. The AVB protocol provides a high-precision clock that significantly reduces harmonic distortion and phase shift, ensuring audio remains clean and clear. PoE allows network cables to carry electrical power to compatible devices, providing both network data, such as digital audio, and electrical power from a single cable. Four of the SW5E's five ports provide PoE, with the fifth port used for networking with additional switches to create a larger network. The robust metal housing is designed to withstand the rigours of road wear and can be rack-mounted using an optional rack tray. The PreSonus SW5E comes with a standard IEC power cord. Ports and indicators - 5 AVB Ethercon sockets - 4 ports with PoE - PoE power indicators - Network link/activity indicators Switches and power - PoE power on/off - Internal power supply with IEC connector Physical characteristics - Robust metal chassis - Rack mountable (screws onto a rack tray)
|
|
Features |
|
|
Ports |
AVB ports: 5, PoE ports: 4 |
|
|
PoE |
PoE supported: IEEE 802.3at-2009 (Type 1) |
|
|
Bandwidth |
Operating bandwidth: 10/100/1 Gb |
|
|
Front panel |
Activity LEDs: 5, Active PoE LEDs: 4 |
|
|
Power supply |
100 to 230 VAC, 50/60 Hz, 65 W |
|
|
Dimensions |
1.7 x 8.5 x 7" / 43.2 x 215.9 x 177.8 mm |
The PreSonus SW5E is a rugged AVB network switch, designed to connect digital audio devices over long distances using CAT5e or CAT6 Ethernet cable. The device provides Power over Ethernet (PoE) and allows for the routing of audio anywhere on the network with extremely low latency.
