Adder - AdderLink Infinity Dual, Dual Head Single Link Receiver

Adder ALIF2020R - AdderLink Infinity Dual, Dual Head Single Link Receiver

1055385
Adder ALIF2020R - AdderLink Infinity Dual, Dual Head Single Link Receiver
Adder ALIF2020R - AdderLink Infinity Dual, Dual Head Single Link Receiver
ADDERLink Infinity ALIF2020R is a high performance Dual-monitor single-link DVI, USB and Audio Receiver for the Adder Infinity Digital KVM Extension / Matrix solution. ALIF2020R receiver requires at least one ALIF2020T transmitter to operate.
... learn more
Visuals Price
1,376.00 CHF VAT excl.

1,487.46 CHF Inc. VAT

Made to order
  • Delivery
    • Shipped in 2 to 3 weeks
  • In-store pickup
    • Available in 2 to 3 weeks



Specifications


Hardware compatibility All computers with DVI-D, USB, audio, RS232 – as required.
DVI-D – Digital Visual Interface (digital only) The system supports two DVI-D Single Link resolutions up to 1920 x 1200 @ 60Hz.
USB 2.0 with class control Supports USB2.0 devices (low, full and high speed). The security function allows non-HID devices to be blocked. Isochronous devices are not supported (for example, USB audio or video devices).
Digital stereo audio The system transfers analogue stereo audio (Line In/Line Out) via digital signalling between any transmitter/receiver pair. Additionally, the audio output from any transmitter can be multicast to multiple receivers.
RS232 RS232 can be transmitted between units up to a maximum baud rate of 115,200. RS232 is a point-to-point connection technology and cannot be multicast.
Software compatibility All known operating systems.
Transmitter (TX) computer connections 2 x DVI-D, 3.5mm audio input, 3.5mm audio output, USB type B, 9-pin D-type RS232, 1 x 8p8c and 1 x SFP for AdderLink Infinity network connections.
Receiver (RX) peripheral connections 2 x DVI-D, 3.5mm audio input, 3.5mm audio output, 4 x USB type A, 9-pin D-type RS232, 1 x 8p8c and 1 x SFP for AdderLink Infinity network connections.
Physical design Compact 1U housing, robust metal construction. 198mm/7.92" (w), 44mm/1.76" (h), 150mm/6.0" (d), 1.1kg/2.7lbs.
Power supply 2.5mm DC socket (mains adapter included), 100-240VAC 50/60Hz, 0.8A, input to mains adapter. 5VDC 20W output from mains adapter.
Operating temperature 0 to 40ºC / 32 to 104ºF.
Approvals CE, FCC.
ADDERLink Infinity ALIF2020R is a high performance Dual-monitor single-link DVI, USB and Audio Receiver for the Adder Infinity Digital KVM Extension / Matrix solution. ALIF2020R receiver requires at least one ALIF2020T transmitter to operate.
