Adder - Adderlink Infinity Dual, Dual Head Single Link Transmitter

Adder ALIF2020T - Adderlink Infinity Dual, Dual Head Single Link Transmitter

1055387
Adder ALIF2020T - Adderlink Infinity Dual, Dual Head Single Link Transmitter
Adder ALIF2020T - Adderlink Infinity Dual, Dual Head Single Link Transmitter
ADDERLink Infinity ALIF2020T is a high performance Dual-link or Dual-monitor DVI, USB and Audio Transmitter for the Adder Infinity Digital KVM Extension / Matrix solution. ALIF2020T transmitter requires at least one ALIF2020R receiver to operate.
... learn more
Visuals Price
1,376.00 CHF VAT excl.

1,487.46 CHF Inc. VAT

Made to order
  • Delivery
    • Shipped in 2 to 3 weeks
  • In-store pickup
    • Available in 2 to 3 weeks



Specifications


Video resolutions DVI-D Single Link resolutions up to a maximum of 1920 x 1200 at 60 Hz
Approvals / Compliance CE
FCC
Standards Supports USB 2.0 devices (low, full and high speed). The security function allows non-HID devices to be blocked. Isochronous devices are not supported (for example, USB audio or video devices).
Cabling requirements Copper (CATx up to 100 m) or Fibre (as required)
Operating temperature 0 to 40 °C / 32 to 104 °F.
Transmitter (Tx) ports DVI-D x 2, 3.5 mm audio input, 3.5 mm audio output, USB Type B, 9-pin D-type RS232, SFP slot
Receiver (Rx)
Video: DVI-D x 2, 3.5 mm audio input, 3.5 mm audio output, USB Type A x 4, 9-pin D-type RS232, SFP slot
Physical design Compact 1U housing, robust metal construction. 198 mm (7.92 in) (W), 44 mm (1.76 in) (H), 150 mm (6 in) (D), 1.1 kg (2.7 lb)
Power supply 2.5 mm DC socket (mains adapter included), 100-240 VAC, 50/60 Hz, 0.4 A, input to mains adapter, 5 VDC, 12.5 W power supply output
Software compatibility All common operating systems
ADDERLink Infinity ALIF2020T is a high performance Dual-link or Dual-monitor DVI, USB and Audio Transmitter for the Adder Infinity Digital KVM Extension / Matrix solution. ALIF2020T transmitter requires at least one ALIF2020R receiver to operate.
