Adder ALIF4001R - AdderLink Infinity Dual Head 4K Receiver
1055396
The ADDERLink INFINITY 4000 Series (ALIF4000) is a dual-head, 5K high-performance IP KVM matrix over a single fiber. It is compatible with the existing ADDERLink INFINITY (ALIF) line and supported by the ADDERLink INFINITY Manager (AIM). The ALIF4001 can be used as a point-to-point extender or easily integrated into a more comprehensive matrix system.
Visuals Price
2,477.00 CHF
VAT excl.
2,677.64 CHF Inc. VAT
Made to order
-
Delivery
- Shipped in 2 to 3 weeks
-
In-store pickup
- Available in 2 to 3 weeks
|
|
Specifications |
|
| Video Information (For 1 Screen) | ||
| Maximum Resolution | 5120 x 2880 | |
| Colour Depth | 10 bpc | |
| Video Information (For 2 Screens) | ||
| Maximum Resolution | 5120 x 2880 | |
| Colour Depth | 10 bpc | |
| Additional Video Information | ||
| Additional Information | Supports resolutions up to 5120 x 2880 including UHD or DCI and refresh rates up to 240Hz. Up to 10-bit per color SDR and HDR10. |
|
| Computer Connections | ||
| USB B | 1× 2.0 Transparent, True Emulation, High Speed | |
| Full Size DisplayPort | 2× | |
| Link Ports | ||
| SFP+ | 2× | |
| Audio Connections | ||
| Audio Type | Analog/Digital | |
| Channels | 2 | |
| Audio In Ports | 1× 3.5mm jack | |
| Audio Out Ports | 1× 3.5mm jack | |
| Size (bit) | 16 | |
| Speed (kHz) | 48 | |
| Additional Information | Analog Line in/out 2 channel 16bit 48KHz 1V RMS in/1V RMS out. 2x DisplayPort™ Audio in either 2, 6 or 8 channels linear PCM |
|
| Network Support | ||
| Bandwidth | 2x 10GbE or 2x 1GbE (no10/100 support) via SFP or; 2x 10,5,2.5GbE and when using SFP-CATX-MR SFP | |
| 10/100 Support | No | |
| Environmental | ||
| Operating Temperature | 0 - 50 °C / 32 - 122 °F | |
| Storage Temperature | 0 - 50 °C / 32 - 122 °F | |
| Operating Humidity (%) | 10% - 90% (non-condensing) | |
| Storage Humidity (%) | 10% - 90% (non-condensing) | |
| Altitude | 2000m / 6561.7ft | |
| Mean Time Between Failure (MTBF) | 159,000 h | |
| Power Source | ||
| 12V 3-pin | 1× | |
| Power Consumption | ||
| Typical Power (Watts) | 20 | |
| Physical Design | ||
| Construction Material | Aluminium and steel construction | |
| Width | 215mm / 8.5in | |
| Height | 40mm / 1.6in | |
| Depth | 210mm / 8.30in | |
| Weight | 1.8kg / 4lb | |
| Compatibility | ||
| OS Compatibility | Windows, macOS | |
| Approvals and Standards | ||
| Approvals | CE, cULus - E476334, FCC, ICES, RCM, UKCA | |
| Standards | ANSI 63.4, EN/IEC 62368-1, EN55032 /CISPR 32, EN55035/CISPR 35, EN61000-3-2, EN61000-3-3, EN63000, FCC pt15B, ICES003 | |
| Other | Cal Prop 65, China ROHS, EU REACH, UK REACH | |
| Packing Box | ||
| Length | 285mm / 11.2in | |
| Width | 245mm / 9.6in | |
| Depth | 145mm / 5.7in | |
| Weight | 2.5kg / 5.5lb | |
| Ordering Information | ||
| Code | Description | |
| ALIF4001T-XX | ALIF4001 Transmitter | |
The ADDERLink INFINITY 4000 Series (ALIF4000) is a dual-head, 5K high-performance IP KVM matrix over a single fiber. It is compatible with the existing ADDERLink INFINITY (ALIF) line and supported by the ADDERLink INFINITY Manager (AIM). The ALIF4001 can be used as a point-to-point extender or easily integrated into a more comprehensive matrix system.
