Adder - AdderLink XD USB (2.0) & Displayport, RS232 & HD Audio KVMA CATx Extender 100 Mtr
Adder XD522-DP-PAIR - AdderLink XD USB (2.0) & Displayport, RS232 & HD Audio KVMA CATx Extender 100 Mtr
1055676
ADDERLink XD522 (XD522-DP-PAIR) is a high performance Dual-monitor DisplayPort KVM (Keyboard, Video, Mouse) extender that enables you to locate your critical computing hardware in a secure and temperature controlled environment away from the user work station whilst maintaining the same user desktop experience.
Visuals Price
1,913.00 CHF
VAT excl.
2,067.95 CHF Inc. VAT
Made to order
-
Delivery
- Shipped in 2 to 3 weeks
-
In-store pickup
- Available in 2 to 3 weeks
The AdderLink XD522 is a high-performance KVM (keyboard, video, mouse) extender that allows you to place your critical computer equipment in a secure and climate-controlled environment, remote from the user workstation, while maintaining the same user experience.
It can transmit either two 1920x1200 video streams or a higher resolution video stream (2560x1600 WQXGA), digital audio (S/PDIF), analogue audio, high-speed USB 2.0 and USB 2.0 (full and low speed) over CATx cables.
FEATURES:
Plug and play
150 metre extension distance for a single 1920x1080 screen
100 metre extension distance for two 1920x1200 screens or a single high-resolution screen up to 2560x1600
Compatible with Mac Cinema Display (2560x1440)
Now supports 4K resolutions (3840x2160 VESA)
High-speed USB 2.0 for mass storage devices and:
Keyboard, mouse, tablet and touch
S/PDIF and analogue audio
Perfect Digital Video, Real-Time Control
The system is uncompressed, every pixel of every frame is transmitted losslessly. The receiver supports dual Display Port mode (DP++), which means that screens that only support HDMI or DVI can be used (with the appropriate adapter cable).
Single CATx Cable
Video, USB 2.0 (HID only) and audio all pass through a single cable. A second CATx cable is required for high-speed USB 2.0 extension.
Extension Distances Up to 150 Metres
The distance depends on the screen resolution, number of screens, cable type and number of connection points for patch panels and wall plates. Refer to the table on the datasheet for more details.
USB 2.0
Allows connection of any USB human interface device, from mice and keyboards to graphics tablets, jog shuttles, joysticks and 3D explorers. Mass storage devices and isochronous devices such as webcams and headsets can be used via the transparent high-speed USB 2.0 port.
EDID Management
The system has intelligent EDID management allowing the true characteristics of the screen to be transmitted to the computer.
Plug and Play
The AdderLink XD522 extender is supplied in a zero-configuration state, so you can plug in the units and start using them immediately. No drivers or software need to be installed.
Digital Audio
Supports S/PDIF interface via 3.5 mm optical socket (dual purpose with analogue audio via mini Toslink).
HD Quality Analogue Audio
HD audio quality (24-bit stereo channel sampled at 96 kHz) is available for transferring audio from local to remote for line in/line out. Microphone and headset use cases are also supported.
4K Resolution Support
Now supports 4K resolutions up to 3840x2160 (VESA timing).
It can transmit either two 1920x1200 video streams or a higher resolution video stream (2560x1600 WQXGA), digital audio (S/PDIF), analogue audio, high-speed USB 2.0 and USB 2.0 (full and low speed) over CATx cables.
FEATURES:
Plug and play
150 metre extension distance for a single 1920x1080 screen
100 metre extension distance for two 1920x1200 screens or a single high-resolution screen up to 2560x1600
Compatible with Mac Cinema Display (2560x1440)
Now supports 4K resolutions (3840x2160 VESA)
High-speed USB 2.0 for mass storage devices and:
Keyboard, mouse, tablet and touch
S/PDIF and analogue audio
Perfect Digital Video, Real-Time Control
The system is uncompressed, every pixel of every frame is transmitted losslessly. The receiver supports dual Display Port mode (DP++), which means that screens that only support HDMI or DVI can be used (with the appropriate adapter cable).
Single CATx Cable
Video, USB 2.0 (HID only) and audio all pass through a single cable. A second CATx cable is required for high-speed USB 2.0 extension.
Extension Distances Up to 150 Metres
The distance depends on the screen resolution, number of screens, cable type and number of connection points for patch panels and wall plates. Refer to the table on the datasheet for more details.
USB 2.0
Allows connection of any USB human interface device, from mice and keyboards to graphics tablets, jog shuttles, joysticks and 3D explorers. Mass storage devices and isochronous devices such as webcams and headsets can be used via the transparent high-speed USB 2.0 port.
EDID Management
The system has intelligent EDID management allowing the true characteristics of the screen to be transmitted to the computer.
Plug and Play
The AdderLink XD522 extender is supplied in a zero-configuration state, so you can plug in the units and start using them immediately. No drivers or software need to be installed.
Digital Audio
Supports S/PDIF interface via 3.5 mm optical socket (dual purpose with analogue audio via mini Toslink).
HD Quality Analogue Audio
HD audio quality (24-bit stereo channel sampled at 96 kHz) is available for transferring audio from local to remote for line in/line out. Microphone and headset use cases are also supported.
4K Resolution Support
Now supports 4K resolutions up to 3840x2160 (VESA timing).
ADDERLink XD522 (XD522-DP-PAIR) is a high performance Dual-monitor DisplayPort KVM (Keyboard, Video, Mouse) extender that enables you to locate your critical computing hardware in a secure and temperature controlled environment away from the user work station whilst maintaining the same user desktop experience.
