Bluebell BCSPLIT1x6 - 1 input, 6 output Optical Splitter

1011919
Bluebell BCSPLIT1x6 - 1 input, 6 output Optical Splitter
Bluebell BCSPLIT1x6 - 1 input, 6 output Optical Splitter
1 input, 6 output Optical Splitter.
... learn more
Visuals Price
966.00 CHF VAT excl.

1,044.25 CHF Inc. VAT

Made to order
  • Delivery
    • Shipped in 2 to 3 weeks
  • In-store pickup
    • Available in 2 to 3 weeks

Bluebell optical splitter 1 input, 6 outputs
The BCSPLIT1xN range is a passive device that splits a single input optical power into multiple optical outputs and acts as a power splitter. Based on Planar Lightwave Circuit (PLC) technology, the BCSLPIT1xN offers superior optical performance, including low insertion loss and low polarisation-dependent loss.
The wide wavelength and operating temperature ranges ensure highly reliable and stable optical performance for critical signal situations.



Specification



General card specifications



Connector:

Single-mode FC

Wavelength:

1260-1625 nm

Return loss:

> 50 dB

Directivity:

> 55 dB

Maximum optical power:

300 mW

Operating temperature:

-40 to 85 °C

Storage temperature:

-40 to 85 °C

Depth:

60 mm

Width:

20 mm 4TE

Height:

100 mm (3RU)

Weight:

100 g



1 input, 6 output Optical Splitter.
