AJA HDMI to SMPTE ST 2110 video and audio IP encoder
Convert a single HD HDMI signal for highly efficient SMPTE ST 2110 IP transmission with the AJA IPT-10G2-HDMI mini-converter. Supporting video up to 1080p60, this mini-converter provides two interfaces for use with separately available 10 GbE SFP+ modules. Seamless SMPTE ST 2022-7 switching for mission-critical transmissions is offered via the redundant interface design.
The IPT-10G2-HDMI mini-converter processes up to eight channels of embedded SDI audio or analogue stereo audio input via its RCA inputs. Control options include a 1 GbE RJ45 LAN socket for customisable browser-based control across all platforms and REST clients, as well as a USB Mini-B port for initial setup and updates.
Versatile power features include a universal power supply with lockable power connector and international adapters, as well as a separately available D-Tap cable for powering the device via battery whilst on the move. The AJA IPT-10G2-HDMI mini-converter features a durable fanless housing, compact enough to be mounted directly on your monitor or camera rig.
Features
- Converts an HD HDMI source to highly efficient SMPTE ST 2100 IP transmission
- Two 10 GbE SFP+ media network cages enabling seamless redundant switching
- One HDMI Type A input supporting video up to 1080p60, 4:2:2, 10-bit YCbCr
- One 1 GbE RJ45 LAN control socket
- Status indicators on SFP+ and RJ45 connectors
- Compact and durable fanless design
- Full 10-bit pixel processing pipeline
- Dual RCA analogue audio input
- One USB Mini-B port for initial setup and updates
- Built-in server enabling full control from any web browser
- Customisable control via AJA REST API




Specifications



Input



Video input connectors

1 x HDMI (HDMI 1.4b) female

Video input format

HDMI (10-bit 4:2:2) 1080p: 23.98/24/25/29.97/30/50/59.94/60 fps 1080i: 50 fps 720p: 50/59.94/60 fps NTSC: 59.94 fps PAL: 50 fps

Audio input connectors

2 x analogue RCA female

Audio input format

AES/EBU: 48 kHz / 24-bit

Embedded audio input

HDMI: 8 channels

Standards



Video standards compliance

SMPTE ST-2022-7/ST-2110

Connectivity



Other I/O

1 x LAN RJ45 input/output 1 x USB Mini-B 1 x BNC reference output

Expansion slots

2 x SFP+ slot

Power supply



Power connector

1 x proprietary input (5 to 20 VDC)

Power consumption

Power supply: 100 to 240 VAC (13 W)

Environment



Operating temperature

32 to 104 °F / 0 to 40 °C

Storage temperature

-40 to 140 °F / -40 to 60 °C

Operating humidity

10 to 90%

General



Dimensions

5.07 x 5.06 x 0.94" / 128.78 x 128.52 x 23.88 mm

Weight

0.6 lb / 272.15 g
