100 W. Active loudspeakers with integrated digital amplifier and DSP technology. The amplifier can be considered as a 2-channel device. This allows separate control of the high-frequency and mid-bass drivers. In combination with multi-channel DSPs, this ensures optimal sound quality, wide dynamic range, flat frequency response and optimal driver protection. A total of three compact broadband models and three subwoofers are available.
Compact 2-way active loudspeaker with aluminium housing for use in a networked digital audio system
Active loudspeaker with integrated 2-channel digital amplifier and DSP technology, equipped with high-quality 2 x 4" / 0.75" dome drivers. The use of neodymium drivers and an aluminium housing makes the loudspeaker very lightweight - approximately 1.9 kg. Ideally suited for dynamic reproduction of speech and music, its elegant design also allows for perfect optical integration. With a capacity of up to 100 W, the loudspeaker can generate a maximum SPL of 116 dB. The loudspeaker has a very precise dispersion of 130° x 80° (h x v) and a wide frequency range of 80 Hz to 20 kHz. Lightweight aluminium housing with rounded sides, black or white powder coating. Optionally available in all RAL Classic colours and in Fohhn Texture Design. Other colour catalogues are also possible on request. To protect the drivers and electronics, the housing is equipped with a high-quality, bulletproof and acoustically transparent front grille made of powder-coated galvanised steel. Four M6 threaded inserts integrated into the base, rear panel and top of the unit are designed to accommodate mounting brackets. CAAD simulation files for EASE are available. Developed for dedicated use in a networked digital audio system comprising active loudspeakers with integrated digital amplifiers and DSP technology, master modules and other system components.
Connections: Input via RJ-45 (Neutrik etherCON) for digital AES/EBU signals, control signals and power supply. Output via RJ-45 link out (Neutrik etherCON) allowing daisy-chain connection to other system components.
|
|
Specifications |
|
|
Electroacoustic characteristics |
|
|
|
Acoustic design |
Compact 2-way nearfield active loudspeaker |
|
|
Components |
2 x 4" dome tweeter, full neodymium |
|
|
Total rated power |
100 W |
|
|
Operating mode |
Active, DSP amplifier 2x Class-D |
|
|
Maximum SPL |
116 dB |
|
|
Frequency range |
80 Hz - 20 kHz |
|
|
Nominal dispersion (h x v) |
130° x 80° |
|
|
Features |
|
|
|
Loudspeaker |
Aluminium housing |
|
|
Protective grille |
Bulletproof steel grille, powder coated |
|
|
Mounting points |
4x M6 thread |
|
|
Standard colours |
Black or white powder coating |
|
|
Front design |
Metal grille in housing colour |
|
|
Dimensions (W x H x D) |
130 x 232 x 120 mm |
|
|
Weight |
1.9 kg |
|
|
Optional features |
|
|
|
Optional colours |
All RAL Classic colours, Fohhn Texture Design |
|
|
Remote control, remote monitoring and simulation |
||
|
Remote control |
AIREA-Net, Fohhn Audio Soft |
|
|
Remote monitoring |
Temperature, protection, signals, power supply, Fohhn-Net, Fohhn Audio Soft, AES/EBU available |
|
|
Fault contact |
- |
|
|
Beam simulation |
- |
|
|
Electronic performance |
|
|
|
Amplifier output |
2 x 300W |
|
|
Amplifier type |
Pure Path Digital PWM |
|
|
Audio inputs |
2 independent audio channels, AES/EBU 32 kHz -96 kHz, 16/24 Bit |
|
|
Audio outputs |
2 x 300W internal |
|
|
DSP channels |
Fohhn Audio DSP |
|
|
Amplification |
30 dB (Ref 1V) |
|
|
Input sensitivity |
-6 dB full scale |
|
|
Frequency response |
20 Hz - 20 kHz |
|
|
Signal-to-noise ratio |
>105 dB/A |
|
|
THD |
< 0.05% typ., < 0.01% 1kHz -6dB |
|
|
Protection circuit |
Soft start, overheating protection, short circuit, overload |
|
|
Power supply |
Airea Net 50V |
|
|
Power handling |
Standby 5 W, Airea Net Load 50W |
|
|
Power factor (PFC) |
> 90% |
|
|
Protection |
Integrated semiconductor fuse |
|
|
Low power consumption |
Green Power standby mode |
|
|
Backup power supply possible |
With external UPS |
|
|
Temperature range |
0 – 40°C |
|
|
Cooling |
Passive |
|
|
Electronics weight |
0.3 kg |
|
|
Controllers |
|
|
|
Digital signal processors |
2 |
|
|
Independent limiters |
4 |
|
|
3-band selective limiting |
Bass/midrange/treble |
|
|
Band-specific time constants |
Yes |
|
|
Filter technology |
Double precision 56 bits |
|
|
Input |
AES/EBU 32kHz – 96kHz, 16/24 Bit |
|
|
FIR filter |
Yes |
|
|
Gain |
-80 dB - +12 dB |
|
|
Volume |
-80 dB - +12 dB |
|
|
EQ |
10-band parametric EQ, Gain, +/-12 dB, Frequency 10 -20 kHz, Q 0.1 – 100 |
|
|
Compressor limiter |
Yes |
|
|
Noise Gate |
Yes |
|
|
Active filter |
Linkwitz-Riley 4th order, 24 dB/octave, high-pass 10 Hz -20 kHz, low-pass 10 Hz - 20 kHz |
|
|
Delay |
0 - 145 ms (0 - 50 m) |
|
|
User presets |
100 |
|
|
System latency |
0.95 ms |
|
