Fohhn - Stage monitor
Fohhn XM-4 - Stage monitor
1003515
The Fohhn® XM-4 is an extremely high-performance stage monitor system in a very compact housing that combines efficiency, speech intelligibility and sound quality with design of the highest quality
PRICE ON REQUEST
Made to order
-
Delivery
- Shipped in 1 to 2 weeks
-
In-store pickup
- Available in 1 to 2 weeks
Fohhn stage monitor
The Fohhn® XM-4 is an extremely robust 2-way high-performance stage monitor system with very compact dimensions, lightweight and surprisingly natural sound. The XM-4 is equipped with a 12" bass/mid chassis and a 3.5" tweeter driver with a 1.4" CD horn. Combined with the extremely sophisticated passive filter and integral electronic loudspeaker protection, this proven configuration guarantees maximum sound and dynamics for voice and drums whilst achieving an exceptional level of transparency. The defined sound dispersion characteristics offer maximum protection against feedback, even at extreme sound levels, and the 80° x 60° dispersion angle reaches the target area on stage with extreme precision. The XM-4 is manufactured to a high degree of precision, is flexible and offers perfect handling and exceptional sound. It is equipped with the latest Neodymium chassis and weighs only 23 kg. The XM-4 is perfectly suited for full-range speech and music applications. This compact enclosure also produces exceptional sound when used in a drum monitor system with subwoofers (XS-4 active, XS-4 passive). The XM-4 has 2 positioning angles as a monitor: 55° and 35°. Rubber feet protect the housing on 3 sides and prevent the monitor from sliding. The cabinets are made from quality multiplex birch wood, have a sealed construction and a scratch-resistant plastic coating. A robust metal grille behind the acoustic foam protects the loudspeaker. 2 recessed handles and minimal weight make the enclosure extremely easy to transport.
Control
The Fohhn® XM-4 is an extremely robust 2-way high-performance stage monitor system with very compact dimensions, lightweight and surprisingly natural sound. The XM-4 is equipped with a 12" bass/mid chassis and a 3.5" tweeter driver with a 1.4" CD horn. Combined with the extremely sophisticated passive filter and integral electronic loudspeaker protection, this proven configuration guarantees maximum sound and dynamics for voice and drums whilst achieving an exceptional level of transparency. The defined sound dispersion characteristics offer maximum protection against feedback, even at extreme sound levels, and the 80° x 60° dispersion angle reaches the target area on stage with extreme precision. The XM-4 is manufactured to a high degree of precision, is flexible and offers perfect handling and exceptional sound. It is equipped with the latest Neodymium chassis and weighs only 23 kg. The XM-4 is perfectly suited for full-range speech and music applications. This compact enclosure also produces exceptional sound when used in a drum monitor system with subwoofers (XS-4 active, XS-4 passive). The XM-4 has 2 positioning angles as a monitor: 55° and 35°. Rubber feet protect the housing on 3 sides and prevent the monitor from sliding. The cabinets are made from quality multiplex birch wood, have a sealed construction and a scratch-resistant plastic coating. A robust metal grille behind the acoustic foam protects the loudspeaker. 2 recessed handles and minimal weight make the enclosure extremely easy to transport.
Control
For maximum sound performance and operational reliability, we recommend our DSP digital amplifiers. (e.g. D-2.1500 and D-4.1200) We always integrate a sophisticated passive filter with electronic high-frequency protection, so the XM-4 can be used with any professional amplifier.
Applications
Stage monitor, live music, playback, speech
Connections
2x NL4 Neutrik Speakon left and right for very easy and safe connection to the next XM-4 stage monitor.
Accessories
Applications
Stage monitor, live music, playback, speech
Connections
2x NL4 Neutrik Speakon left and right for very easy and safe connection to the next XM-4 stage monitor.
Accessories
High-quality padded transport cover; flight case for always 2 monitors in transport space version.
High-performance 2-way stage monitor enclosure
High-performance 2-way stage monitor enclosure equipped with a 12" bass/mid loudspeaker and a 3.5" tweeter driver on a 1.4" CD horn. The enclosure is capable of temporarily operating under 2000 W and generates a maximum sound pressure of 131 dB. In a wide frequency range from 45 Hz to 20 kHz, the enclosure has a defined dispersion of 80° x 60° (h x v). High-strength multiplex birch wood cabinet with different positioning angles for use as stage monitor. Black scratch-resistant and water-repellent polyurethane coating. For protection of loudspeakers and electronics, the cabinet is equipped with an impact-resistant front grille, extremely permeable to sound, made of powder-coated steel and fitted with moisture and dust-resistant acoustic foam in the cabinet colour. Connection: 2x Neutrik NL4 Speakon, each integrated in the left and right handles.
High-performance 2-way stage monitor enclosure
High-performance 2-way stage monitor enclosure equipped with a 12" bass/mid loudspeaker and a 3.5" tweeter driver on a 1.4" CD horn. The enclosure is capable of temporarily operating under 2000 W and generates a maximum sound pressure of 131 dB. In a wide frequency range from 45 Hz to 20 kHz, the enclosure has a defined dispersion of 80° x 60° (h x v). High-strength multiplex birch wood cabinet with different positioning angles for use as stage monitor. Black scratch-resistant and water-repellent polyurethane coating. For protection of loudspeakers and electronics, the cabinet is equipped with an impact-resistant front grille, extremely permeable to sound, made of powder-coated steel and fitted with moisture and dust-resistant acoustic foam in the cabinet colour. Connection: 2x Neutrik NL4 Speakon, each integrated in the left and right handles.
|
|
Specifications |
|
|
Electro-acoustic characteristics |
|
|
|
Acoustic design |
Passive stage monitor, 2-way, bass reflex |
|
|
Components |
12" / 1.4" on rotatable CD horn, with automatic reset IPC[*]-HF protection, fully neodymium |
|
|
Nominal power (rated) |
500 W |
|
|
Nominal power (programme) |
1000 W |
|
|
Nominal power (peak) |
2000 W |
|
|
Sensitivity |
100 dB |
|
|
Maximum SPL |
131 dB |
|
|
Frequency range |
45 Hz – 20 kHz |
|
|
Nominal dispersion (h x v) |
80° x 60° |
|
|
Nominal impedance |
8 ohms |
|
|
Characteristics |
|
|
|
Enclosure |
Asymmetric, multifunctional cabinet in birch plywood |
|
|
Protective grille |
Metal, powder-coated finish |
|
|
Connections |
2x Neutrik NL4 Speakon, left and right |
|
|
Standard colour |
Scratch-resistant plastic coating, black |
|
|
Front design |
Acoustic foam |
|
|
Dimensions (W x H x D) |
Approximately 590 x 340 x 450 mm |
|
|
Handles |
2 recessed handles |
|
|
Positioning angle as monitor |
55° and 35° |
|
|
Speaker stand socket |
Integral, ø 36 mm |
|
|
Weight |
Approximately 23 kg |
The Fohhn® XM-4 is an extremely high-performance stage monitor system in a very compact housing that combines efficiency, speech intelligibility and sound quality with design of the highest quality
