Specifications

Configuration

2-way passive

Speaker type

Bass-reflex speaker enclosure

Total power

250 W RMS 500 W Programme 1000 W Peak

Constant voltage / Transformer taps

None

System impedance

8 Ohms

Speakers

Tweeter

1 x 35.6 mm compression driver with 25 mm throat

Midrange driver

None

Woofer

1 x 381 mm Woofer

Woofer voice coil

63.5 mm

Magnet

Ferrite

Performance

Frequency response

49 Hz to 20 kHz -10 dB

Maximum SPL

125 dB

Coverage angle

90° H x 60° V

Speaker sensitivity

95 dB SPL

Connectivity

Audio inputs/outputs

2 x NL4 SpeakON speaker input/output (lockable)

Signal processing

Filter

2 kHz

Phase adjustment

None

Physical characteristics

Mounting

2 x M10 rigging points (top) 1 x M10 rigging point (rear) 1 x 35 mm pole mount (bottom)

Handles

1 x Each side

Construction material

Plywood, Polyurethane

Dimensions

690.9 x 431.8 x 403.9 mm

Weight

22 kg
