Specifications

PA speaker

Configuration

2-way passive

Speaker type

Bass-reflex speaker

Total power

Passive:
350W RMS
700W Programme
1400W Peak
Bi-Amp / LF:
350W RMS
700W Programme
1400W Peak
Bi-Amp / HF:
50W RMS
100W Programme
200W Peak

System impedance

8 Ohms (Passive)
LF:
8 Ohms (Bi-Amp)
HF:
16 Ohms (Bi-Amp)

Speakers

HF driver

1 x Rotatable horn with 1" / 25.4 mm titanium compression driver

HF voice coil

2" / 50.8 mm

LF driver

1 x 10" / 25.4 cm woofer

LF voice coil

3" / 76.2 mm

Magnet

HF:
Neodymium
LF:
Neodymium

Performance

Frequency response

43 Hz to 20 kHz -10 dB

Maximum SPL

127 dB SPL (Peak, Passive)
127 dB SPL (LF, Peak, Bi-Amp)
131 dB SPL (HF, Peak, Bi-Amp)

Coverage angle

90° H x 60° V (Rotatable horn)
60° H x 90° V (Monitor)

Speaker sensitivity

Passive:
95 dB SPL
Bi-Amp/LF:
95 dB
Bi-Amp/HF:
108 dB SPL

Connectivity

Audio inputs/outputs

2 x speakON NL4

Signal processing

Crossover filter

2.5 kHz

Physical characteristics

Mounting

2 x Pole cup 1.4" / 35 mm (Dual angle, Top)
8 x M10 rigging points
2 x M8 rigging points

Monitor angle

50°

Handles

1 x On each side

Construction material

Plywood

Dimensions

12.4 x 21.1 x 13.6" / 315 x 537 x 345 mm

Weight

30.9 lb / 14 kg
