Specifications

Configuration

2-way active

Enclosure Type

Bass-reflex enclosure

Total Power

465 W RMS
1000 W peak

Amplification Power

Highs:
1 x 200 W
Lows:
1 x 800 W

Amplification Class

Class D

Speakers

Tweeter

1 x 1.75" / 44.45 mm horn compression driver with 1" / 25 mm throat

Mid-range Speaker

None

Woofer

1 x 15" / 381 mm woofer

Voice Coil Bass

2.5" / 63.5 mm

Magnet

Ferrite

Performance

Frequency Response

44 Hz to 20 kHz -10 dB

Maximum SPL

131 dB

Coverage Angle

90° H x 60° V

Protection

DC fault, output limiter, overcurrent, overvoltage, power supply, thermal

Connectivity

Audio I/O

1 x Balanced/unbalanced mic/line combo XLR-6.35 mm jack female 3-pin input
1 x Balanced/unbalanced line combo XLR-6.35 mm jack female 3-pin input
1 x Unbalanced stereo RCA TS female line input
1 x Balanced line XLR male 3-pin output/through

Network I/O

None

USB

None

Wireless Connectivity

None

Signal Processing

Filter

1.8 kHz

Equaliser

None

Parametric Equaliser

None

Semi-parametric Equaliser

None

Alignment Delay

None

Phase Adjustment

None

Digital Signal Processing

Room Settings

Maximum Sample Rate/Resolution

48 kHz / 24-bit

Power Supply

Mains Power

100 to 240 VAC, 50 / 60 Hz

Mains Power Connector

1 x IEC input

Power Consumption

18 W (idle)
74 W (1/8 power)

Physical Characteristics

Mounting

2 x M10 flying points (top)
1 x M10 flying point (rear)
1 x 1.4" / 35 mm pole socket (dual angle, bottom)

Handles

1 x Each side

Construction Material

Metal grille, plywood, polyurethane

Dimensions

27.2 x 17 x 15.9" / 690.9 x 431.8 x 403.9 mm

Weight

52.9 lb / 24 kg
