Kramer C-BM/BM-10 - Molded BNC (Male - Male) Cable (10')

1036131
Kramer C-BM/BM-10 - Molded BNC (Male - Male) Cable (10')
Kramer C-BM/BM-10 - Molded BNC (Male - Male) Cable (10')
Molded BNC (Male - Male) Cable (10')
... learn more
Visuals Price
21.25 CHF VAT excl.

22.97 CHF Inc. VAT

Manufacturer price 25,00 CHF VAT excluded
Made to order
  • Delivery
    • Shipped in 1 to 2 weeks
  • In-store pickup
    • Available in 1 to 2 weeks

Kramer Moulded BNC Cable (Male - Male) (3.05 m)
Kramer's C−BM/BM is constructed with high-performance RG−6 cable equipped with 75Ω BNC connectors at each end. It offers exceptional quality, durability and performance for any video signal application.
Features
- Quality construction — RG–6 cable for the highest resolution signals.
- High-quality connectors — True 75Ω BNC connectors maintain correct end-to-end impedance.
- Wide selection of lengths — Available in lengths from 0.46 to 45.7 m (1.5 to 150 feet).
- Cable specifications — Tested up to 3G. For detailed cable specifications, see Kramer BC–1X.




Specifications



Conductor

Solid bare copper 18 AWG

Dielectric

Foam Skin

Shielding

A: 61% braid in 34 AWG aluminium wire
B: Double foil/Mylar with 25% overlap rate

Outer Jacket

PVC

Centre Conductor

1.02 mm (0.0403 in)

Dielectric

4.57 mm (0.179 in)

Outer Diameter

6.95 mm (0.391 in)

Impedance

75 Ω

DC Resistance

21.8 Ω/km (6.6 Ω/304.8 m)

Capacitance

53.1 pF/m (16.1 pF/ft)

Propagation Velocity

82%

Temperature

–20° to 75°C (–4° to 167°F)

Attenuation (dB/30.48 m)

–0.3 dB at 1 MHz
–0.6 dB at 5 MHz
–0.8 dB at 10 MHz
–1.6 dB at 50 MHz
–2.0 dB at 100 MHz
–2.8 dB at 180 MHz
–4.4 dB at 400 MHz
–5.7 dB at 750 MHz
–6.7 dB at 1000 MHz

Regulatory

UL: CL2
CSA: C(UL) CL2



Molded BNC (Male - Male) Cable (10')
