Sennheiser - 4-Way Passive True Diversity antenna splitter/combiner
Sennheiser SL PASC 4 - 4-Way Passive True Diversity antenna splitter/combiner
1026850
4044155253474
4-way passive True Diversity antenna splitter / combination for SpeechLine Digital Wireless system. 2 RF inputs and 8 RF outputs, DECT range (1880 - 1930 MHz)
Visuals Price
689.44 CHF
VAT excl.
745.29 CHF Inc. VAT
Manufacturer price 757,63 CHF VAT excluded
Made to order
-
Delivery
- Shipped in 1 to 2 weeks
-
In-store pickup
- Available in 1 to 2 weeks
Sennheiser 4-Way Passive True Diversity Antenna Splitter/Combiner
The Sennheiser SL PASC 4 is a passive, four-channel true diversity antenna splitter/combiner for the SpeechLine Digital Wireless microphone series.
It is used to distribute the antenna signals from up to four SpeechLine Digital Wireless radio links. In combination with the AWM 2 or AWM 4 remote antennas (both available separately), the number of required antenna cables is reduced to a minimum.
Connect the SL PASC 4 to the rack receivers using the supplied SMA-RP cables.
Features
- Four-channel passive antenna combiner/splitter
- 1880 to 1930 MHz (DECT range)
- 8 x RF outputs for connecting up to four SL Rack Receiver DW units
- 2 x RF inputs to connect an AWM 2 or AWM 4 antenna
- 10 x RP-SMA (AC coupled) connectors
- 8 x SMA-RP cables
The Sennheiser SL PASC 4 is a passive, four-channel true diversity antenna splitter/combiner for the SpeechLine Digital Wireless microphone series.
It is used to distribute the antenna signals from up to four SpeechLine Digital Wireless radio links. In combination with the AWM 2 or AWM 4 remote antennas (both available separately), the number of required antenna cables is reduced to a minimum.
Connect the SL PASC 4 to the rack receivers using the supplied SMA-RP cables.
Features
- Four-channel passive antenna combiner/splitter
- 1880 to 1930 MHz (DECT range)
- 8 x RF outputs for connecting up to four SL Rack Receiver DW units
- 2 x RF inputs to connect an AWM 2 or AWM 4 antenna
- 10 x RP-SMA (AC coupled) connectors
- 8 x SMA-RP cables
|
|
Specifications |
|
|
Type |
4-Channel, Connects to a maximum of Four Receivers |
|
|
Frequency Band |
DECT: 1880 to 1930 MHz |
|
|
Connectors |
10 x RP-SMA (AC-Coupled) |
|
|
Attenuation |
8 dB Typ. |
|
|
Input Power |
1.5 W, Max |
|
|
Colour |
Black |
|
|
Operating Temperature |
-40 to 185°F / -40 to 85°C |
|
|
Dimensions |
8.3 x 6.3 x 1.6" / 210.0 x 160.0 x 41.0 mm |
|
|
Weight |
23.4 oz / 663.0 g |
