Specifications

Configuration

Active 2-Way

Enclosure Type

Bass-Reflex Loudspeaker

Total Power Capacity

325 W RMS
 700 W Peak

Amplifier Power Rating

LF:
 500 W Peak
HF:
 200 W Peak

Amplifier Class

Class-D

Drivers

HF Driver

1 x 1.4" / 35.6 mm Rotatable Horn Compression Driver with 1" / 25 mm Throat

MF Driver

None

LF Driver

1 x 10" / 254 mm Woofer

LF Voice Coil

2" / 50.8 mm

Magnet

Ferrite

Performance

Frequency Range

52 Hz to 20 kHz -10 dB

Maximum SPL

128 dB

Coverage Angle

90° H x 60° V (Rotatable Horn)

Protections

DC Fault, Dynamic Clip, Overcurrent, Overvoltage, Power Supply, Thermal

Connectivity

Audio I/O

1 x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line Input
1 x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Line Input
1 x Stereo RCA TS Female Unbalanced Line Input
1 x XLR 3-Pin Male Balanced Line Thru/Output

Network I/O

None

USB

None

Wireless Connectivity

None

Signal Processing

Crossover

1.9 kHz

EQ

None

Parametric EQ

None

Semi-Parametric EQ

None

Filters

High-Pass:
 100 Hz / 120 Hz

Alignment Delay

None

Phase Adjustment

None

Digital Signal Processing

Venue Settings

Max Sample Rate/Resolution

48 kHz / 24-Bit

Power

AC Input Power

100 to 240 VAC, 50 / 60 Hz

AC Power Connector

1 x IEC Input

Power Consumption

18 W (Idle)
 60 W (1/8 Power)

Physical

Mounting

2 x M10 Fly Point (Top)
1 x M10 Fly Point (Rear)
1 x 1.4" / 35 mm Pole Socket (Bottom)

Handles

1 x Top

Construction Material

Perforated Metal Grille, Plywood, Polyurethane

Dimensions

19.5 x 12 x 11.8" / 495.3 x 304.8 x 299.7 mm

Weight

33.1 lb / 15 kg
