Specifications

Image Sensor

Sensor

35mm Full Size CMOS Sensor

Filter

Filter

Effective pixels per sensor

Approx. 2.26MP (2000 x 1128)

Minimum illumination

0.0005 lux or less (Gain 75dB, f/1.2, shutter speed 1/30, 50 IRE, custom picture [Off])

Horizontal Resolution

Depending on selected lens

Lens

Lens Mount

Canon EF mount with Cinema Lock

ND filter

Yes, 2  density (1/8, 3 stops or 1/64, 6 stops) Manually selected electronic control

Focus control

Manual Focus, One Shot AF

Iris control

Manual;  1/2 stop increments, 1/3 stop increments, fine adjustment. Push Auto Iris via assignable button. Auto (combined function combining Iris, Gain, Shutter and ND filter operation)

Aperture range

Depending on selected lens

Filter diameter

Filter diameter

Image stabilization system Image stabilization system

No

Digital Teleconverter

Digital Teleconverter

Image Processor

Type

DIGIC DV 4

Sampling accuracy

YbCbCr 422 via 3G/HD-SDI; RGB 444, YCbCr 444, YCbCr 422 via HDMI

Bit depth

10 bit (8 bit effective)

Network processor

Type

DIGIC NET II

Server

Simultaneous Client Access

Max. 30 Clients + 1 Admin Client
– H.264: Max. 10 Clients

Bit Rate Control

Variable bit rate / Constant bit rate
Target Bit Rate:

64/128/256/384/512/768/1024/1536/2048/3072/4096/6144/8192/10240/12288/14336/16384 kbps

ADSR: Area-specific Data Size Reduction

Number of Specified Areas: Max. 8 areas
Data Size Reduction Level: 3 levels

Security

Camera Control: Administrator, Authorized user, Guest user (level of control varies depending on user)
Access Control: User authority (user name and password), Host Access Restrictions (IPv4, IPv6)
IEEE802.1X: EAP-MD5, EAP-TLS, EAP-TTLS, EAP-PEAP
Encrypted Communications: SSL/TLS, IPsec

Protocols

IPv4, IPv6, TCP/IP, UDP, HTTP, FTP, SNMPv1/v2c/v3 (MIB2), DHCP, DNS, AutoIP, mDNS, ARP, ICMP, POP3, NTP, SMTP, RTP/RTCP, RTSP, SSL/TLS, IPsec, ONVIF, WV-HTTP (Canon proprietary)

ONVIF Profile

Profile-S, Profile-G

Audio Compression Method

G.711 μ-law (64 kbps)

Audio Communication Method

Full-duplex (two-way)/half-duplex
RTP, Sound Transfer Protocol by Canon

Privacy Mask

Number of registration: Max. 8 places, Number of mask colors: 1 (select from 9 colors)

Preset

Digital PTZ and Camera setting
Number of registration: Max. 20 positions (+Home Position)

Intelligent Function (Video)

Moving Object Detection, Abandoned Object Detection, Removed Object Detection, Camera Tampering Detection, Passing Detection, Intrusion Detection
Number of registration: Max. 15
Non-detection Area Settings: Available

Event Trigger Type

External Device Input, Intelligent Function (Video), Timer, Infrared Switching

Log Notification

SMTP (e-mail)

Image Cropping Function

Cropping sizes: 640 x 360/512 x 288/384 x 216/256 x 144/128 x 72

On-Screen Display

Available
German/English/Spanish/French/Italian/Russian/Turkish/Japanese

Daylight Saving Time

Available

Video output

Network Terminal

Video Compression Method

JPEG, MPEG4-AVC/H.264

Video Quality

10 levels

Video size and Frame Rate

JPEG: 1920 x 1080: 0.1 – 30 fps
MPEG4-AVC/H.264: 1920 x 1080: 1/2/3/5/6/10/15/30 fps
– Only the following combination is available for video output via a network. System frequency: 59.94 Hz, Frame rate: 29.97P, Resolution: 1920 x 1080
– Values represent streaming performance from the camera.
– The frame rate may be reduced due to Viewer computer's specs, the number of clients accessing at the same time, network loads, video quality setting, type or movement of the subject or other reasons.
Maximum frame rate when used in the following combinations:
When streaming H.264(1) (1920 x 1080) and H.264(2) (all sizes) simultaneously: 15 fps
When streaming H.264(1) (all sizes) and H.264(2) (1920 x 1080) simultaneously: 15 fps

I-Frame Interval

0.5/1/1.5/2/3/4/5 sec.

3G/HD-SDI or HDMI Terminal

Video size and Frame Rate

3G/HD-SDI Output: 1920x1080: 59.94P/59.94i/50P/50i/29.97P/25P/23.98P
1280x720: 59.94P/50P/29.97P/25P/23.98P
HDMI Output: 1920x 1080: 59.94P/59.94i/50P/50i/29.97PsF/25PsF
1280x720: 59.94P/50P
640x480: 59.94P
768x576: 50P
* A 1920 x 1080 black video is output on the network connection when selecting a frame rate other than 29.97P

Shooting functions

Exposure

Exposure metering

Backlight, Standard, Spotlight

Exposure Compensation

Yes: ±2.0, ±1.75, ±1.50, ±1.25, ±1.0,±0.75, ±0.50, ±0.25 or ±0

Exposure Lock

No

Auto Gain Control setting

Yes , OFF (75dB) or value from 36dB to 75 dB (in 3 dB increments)

ISO Sensitivity

Maximum in excess of ISO 4,000,000 equivalent at -75dB

Dynamic Range

Canon Log/Wide DR mode: 800%/12 stops at +9.0dB (Approx. ISO2300)

Gain setting

0dB  to -75dB in 3dB intervals.
